Analgesic Effect of Quadratus Lumborum Block Type III and Type II Versus Lateral Transversus Abdominis Plane Block in Cesarean Section: A Randomized Controlled Multicenter Trial

Cesarean section (CS) is accompanied by considerable postsurgical pain (1). Efficient pain control allows early mobilization and supports maternal care for the newborn. Although there are various drug options and administration routes, efficient and safe pain control methods after CS are still under investigation (2).

Commonly, opioids are used for post-CS pain relief. However, adverse events, such as nausea, vomiting, pruritus, and sedation, continue to be significant problems with opiates (3). In addition, opioid secretion during lactation continues to be a unique consideration after CS (4).

The transversus abdominis plane block (TAPB) is administered between the internal oblique muscle and the transversus abdominis muscle in the fascial plane, directly pointing to the somatic nerves T6 - L1 that run in this plane (5). In addition, meta-analyses demonstrate that it is an effective analgesic for somatic pain and diminishes opiate intake (6, 7). It has been reported that the TAPB is an efficient analgesic approach following CS (2).

The quadratus lumborum (QL) muscle block (QLB) is a fascial plane block as a local anesthetic (LA) is introduced nearby to the QL muscle to numb the thoracolumbar nerves. Quadratus lumborum block is categorized into four types according to drug administration location: I (lateral), II (posterior), III (anterior/transmuscular), and IV (intramuscular) (8-10). Quadratus lumborum block can effectively decrease both visceral and somatic pain by LA distribution to the thoracic paravertebral space (TPVS), as this block ensures effective pain control from the T7 to L1 dermatomes (11). Quadratus lumborum block is one of the regional techniques that provide the greatest benefit in post-CS pain control, as it is progressively applied in obstetric anesthetic practice to improve analgesic results (12-14).

The quadratus lumborum block is an easy-to-perform superficial fascial block between the posterior abdominal wall muscles (between QL and erector spinae) (15). With a simpler approach, the QL muscle separates the needle tip from the peritoneum, minimizing the risk of intraperitoneal perforation and bowel injury (9). The reason for the better analgesic effect of QLB type III than TAPB observed in the present trial might be due to the distribution of the drug along the thoracolumbar fascia and end of thoracic fascia into TPVS, which is covered with adipocytes and for which the local tissue blood supply is low, resulting in slow blood absorption of the LA agent (16). Additionally, QLB results in substantial sensory blocks, compared to TAPB (T10-L3 vs. T10-T12) (17).

In the QLB, LA spreads from its lumbar cranial deposition into the TPVS; this could explain why QLB seems able to improve the pain of somatic and visceral types and why QLB could pose an analgesic effect following abdominal procedures (18). Transversus abdominis plane block, on the other hand, involves penetration into the anterior abdominal wall and blocks only somatic fibers (19).

The quadratus lumborum block offered longer-lasting and more effective analgesia than the TAPB up to 72 hours after CS (16, 20-23). However, it has not yet been established which approach of QLB is superior to TAPB as the other QLB techniques for analgesia postoperatively in CS.

This randomized single-blinded trial was carried out to compare the QLB type III and type II versus TAPB regarding efficacy in CS.

This randomized, controlled, single-blind trial incorporated 60 women aged 18 to 40 years, with American Society of Anesthesiologists (ASA) physical status II, presenting for elective CS in Tanta University hospitals and Benha Teaching Hospital in Egypt from March 2023 to June 2023. The study was carried out with the approval of the ethics committee of the general authority for teaching hospitals and institutes on 22/03/2023 (approval code: HB000132) and registration of clinicaltrials.gov (ID: NCT05950568). All cases provided signed, informed consent.

The exclusion criteria were body mass index (BMI) ≥ 40 kg/m², weight < 50 kg, height < 150 cm, contraindications for the use of active labor, spinal anesthesia, recent opiate intake, hypersensitivity to any used medication, or substantial cardiovascular, renal, or hepatic diseases.

The cases were allocated randomly to either the QLB type III, QLB type II, or TAPB group on a 1: 1: 1 ratio in a parallel manner basis using a computer-generated randomization sequence. A piece of paper containing the procedure’s name was placed inside an envelope, and each envelope was assigned a number based on the arrays of numbers in the chart. The outcome assessor was blinded for group allocation.

Preoperative evaluation involves taking history, clinical examination, and routine laboratory tests. During the preoperative anesthesia visit, the participant was educated on the trial’s methodology and pain rating by the numerical rating scale (NRS).

Following cannula insertion, each patient received 500 mL of Ringer’s lactate solution in the operating room as a preload. Regular monitoring (e.g., temperature probe, noninvasive blood pressure, pulse oximetry, and 5-lead electrocardiogram [ECG]) were employed in this study. Cesarean section was performed under spinal anesthesia with 2 - 2.5 mL heavy bupivacaine 0.5% without adjuvants. Blocks were performed at the end of surgery by an anesthesiologist with comprehensive experience in ultrasound (US) guidance nerve block.

3.1. Quadratus Lumborum Block Technique

Quadratus lumborum block was performed when the patient was positioned laterally decubitus. The low-frequency convex probe (Philips CX50 Extreme edition) was put in the flanks and moved to determine the transverse processes of the L2 or L3, the erector spinae, the psoas, and the QL muscles. A 22 G needle was advanced in the plane and positioned between the psoas and QL muscles at the anterior fascia lumbosacral in QLB III and between the QL muscle posterior border and the erector spinae muscle in the thoracolumbar fascia’s middle layer in QLB II. After negative aspiration, 2 mL of saline was administered to ascertain the needle's location. Hydro-dissection of the injectate at a location of concern of lumbosacral fascia and surrounding structure was depicted in real-time. Each side was then injected with 20 mL of bupivacaine 0.25% (Figures 1 and 2).

Figure 1.

Quadratus lumborum block technique type III (A) position and (B) ultrasound image (IC, iliac crest; PM, psoas major; QL, quadratus lumborum; ES, erector spinae; LD, latissimus dorsi; TP, transverse process).

Figure 2.

Quadratus lumborum block technique type II (A) position and (B) ultrasound image (IC, iliac crest; N, needle; QL, quadratus lumborum muscle).

3.2. Transversus Abdominis Plane Block Technique

Transversus abdominis plane block was performed when the patient was positioned in the supine decubitus. A linear high-frequency transducer (Philips CX50 Extreme edition) was placed transversely on the anterolateral abdominal wall between the iliac crest and the costal margin. Under US guidance, the three layers of muscles, the external oblique, the internal oblique, and the transversus abdominis, were identified. A 22-gauge, 100-mm needle was then injected through the skin anteriorly in the plane and advanced into the fascial plane between the internal oblique and transversus abdominis muscles, with its tip lying in the mid-axillary line. To assist with identifying these structures, the probe was moved anteriorly to the rectus sheath, and the fascial planes followed laterally. Following negative aspiration, 2 mL of saline was injected to ascertain the needle location upon the visualization of the transversus abdominis. Each side was then implanted with 20 mL of bupivacaine 0.25% (Figure 3).

Figure 3.

Transversus abdominis plane block technique (A) position and (B) ultrasound image (CM, costal margin; IC, iliac crest; U, umbilicus; N, needle; EO, external oblique muscle; IO, internal oblique muscle; TA, transversus abdominis muscle; LA, local anesthetic).

In this study, 81 cases were evaluated for eligibility, and 21 cases were excluded. The remaining cases were allocated randomly to three groups (20 patients each). All allocated cases were followed up and statistically analyzed (Figure 4).

Figure 4.

CONSORT flowchart of the enrolled patients

Demographic information and duration of surgery were comparable between the studied groups (Table 1).

Postoperative HR and MAP measurements at the PACU at 2, 4, 18, and 24 hours were matched among the three groups; however, at 6, 8, and 12 hours were lower significantly in the QLB III group than in the QLB II group and TAPB group (P < 0.05) without a significant difference between QLB II and TAPB groups (Figure 5).

Figure 5.

Heart rate (HR) (A) and mean arterial blood pressure (MAP) (B) of the studied groups (PACU, post-anesthesia care unit).

The numerical rating scale measurements at the PACU at 2, 4, 18, and 24 hours were comparable among the three groups; however, at 6, 8, and 12 hours were lower significantly in the QLB III group than in the QLB II group and TAPB group (P < 0.05) without a significant difference between QLB II and TAPB groups (Table 2).

The mean ± SD of the first analgesia request time was 12.9 ± 3.21, 7.1 ± 1.1, and 7.4 ± 1.6 hours in the QLB III, QLB II, and TAPB groups, respectively. The mean ± SD of the total amount of meperidine in the first 24 hours after the operation was 77.6 ± 15.96, 99.3 ± 27.8, and 91.4 ± 18.57 mg in the QLB III, QLB II, and TAPB groups, respectively. The time of the first analgesia request was significantly delayed in the QLB III group in comparison to the QLB II and TAPB groups (P < 0.001), with an insignificant difference between the QLB II and TAPB groups. The total amount of meperidine in the first 24 hours after the operation was significantly lower in the QLB III group than in the QLB II and TAPB groups (P < 0.001), with an insignificant difference between the QLB II and TAPB groups (Table 3). Patient satisfaction and adverse events (e.g., hypotension, bradycardia, and PONV) were insignificantly different among the three groups (Table 3).

Regional anesthesia is a promising approach for pain control after CS because it facilitates early mobility and breastfeeding deprived of opioid-associated side effects (25, 26). According to the results of the present study, QLB III ensured better analgesia as evidenced by NRS measurements at 6, 8, and 12 hours, and the total consumed meperidine in the first 24 hours after the operation was significantly lower in the QLB III than in the QLB II and TAPB groups without significant differences between the QLB II and TAPB groups. The time of the first rescue for analgesia was delayed significantly in the QLB III group in comparison to the QLB II and TAPB groups, without a significant difference between the QLB II and TAPB groups.

Some investigations have demonstrated that the QLB could ensure a superior analgesic effect to the TAPB in cases undergoing CS (23, 27).

To the best of our knowledge, this is the first study that compares the two approaches of QLB (II and III) to TAPB in CS. The latest systematic review and meta-analysis by Liu et al. (28) revealed that after abdominal surgery, the QLB ensured excellent pain control with less consumption of opiates than the TAPB. In addition, the QLB offered longer-lasting and more effective analgesia than the TAPB up to 72 hours after CS (16, 20-23). Recently, the QLB was much more effective than TAPB after CS (29, 30).

Regarding comparing the two QLB approaches, the results of the present study are in line with the results of Megawer et al., who reported that QLB type III provided significantly better analgesia than type II after CS (31). This finding could be justified as LA spread more deeply into tissues in QLB III.

In a separate study involving volunteers, QLB III was administered 1 hour after a magnetic resonance (MR) examination. The conclusions demonstrated the injection distribution through the QL and psoas muscles in a cranial direction (32). Additionally, Koksal et al. (33) reported that consumed morphine reduced significantly in the QLB-III than in the QLB-II group. The QLB-III group showed reduced considerably resting pain scores after CS.

Moreover, in a previous study, QLB III offered more efficient, longer-duration analgesia postoperatively and reduced opiate consumption than QLB II in cases undergoing repair of an open inguinal hernia under spinal anesthesia (34). Furthermore, it was observed that the consumption of morphine and pain scores reduced significantly in QLB III than in QLB II after CS (35). The results of the current study revealed that patient satisfaction and adverse events insignificantly differed among the three groups. Similar findings were obtained in other studies (20, 31).
