A Pediatric Parathyroid Carcinoma: An Unusual Clinical Presentation and Mini-review

authors:

avatar Abbas Rahimi 1 , avatar Roghayeh Shahbazi 2 , avatar Pooneh Nikuei 3 , avatar Sanaz Soleimani 3 , avatar Azadeh Moradkhani 3 , avatar Ali Atashabparvar ORCID 3 , avatar Farnaz Khajehrahimi 4 , avatar Ghazal Zoghi ORCID 3 , avatar Masoumeh Kheirandish ORCID 3 , *

Department of General Surgery, Faculty of Medicine, University of Medical Sciences, Bandar Abbas, Iran
Department of Cellular and Molecular Medicine, University of Ottawa, Ottawa, Canada
Endocrinology and Metabolism Research Center, Hormozgan University of Medical Sciences, Bandar Abbas, Iran
Department of Nuclear Medicine, Faculty of Medicine, Hormozgan University of Medical Sciences, Bandar Abbas, Iran

how to cite: Rahimi A, Shahbazi R, Nikuei P, Soleimani S, Moradkhani A, et al. A Pediatric Parathyroid Carcinoma: An Unusual Clinical Presentation and Mini-review. Int J Endocrinol Metab. 2021;19(1):e110234. https://doi.org/10.5812/ijem.110234.

Abstract

Introduction:

Primary hyperparathyroidism (PHPT) is a rare condition in the pediatric population. Parathyroid carcinoma (PC) is a very uncommon cause of PHPT, accounting for < 1% of pediatric PHPT cases. It is challenging to distinguish between parathyroid adenoma (PA), the most common cause of PHPT, and PC. In this report, we described a young female who presented with a history of progressive limping and was finally diagnosed with PC.

Case Presentation:

A 15-year-old girl presented with progressive limping and bone pain for 8 years. She was referred by an orthopedic surgeon because of elevated intact parathyroid hormone (iPTH) for further evaluation. Physical examination revealed a large, firm, and non-tender neck mass, left hip tenderness, and limited range of motion. The initial biochemistry tests showed a borderline high calcium level of 10.8 mg/dl, an elevated iPTH level of 2876 pg/mL, and a decreased phosphorus level of 2.4 mg/dL. The 99mTechnetium (Tc) sestamibi scan displayed early intense activity in the right thyroid lobe persisting in the three-hour repeat scan, compatible with a parathyroid lesion. The patient underwent right-sided neck exploration and parathyroidectomy. Intraoperative and pathology findings confirmed the diagnosis of PC. Immunohistochemistry (IHC) staining revealed creatine kinase (CK) and CD31 in endothelial cells of the tumor. Ki67 staining was also positive in 2% - 3% of tumor cells. The whole exome sequencing (WES) study was negative for cell division cycle 73 (CDC73) and multiple endocrine neoplasia 1 (MEN1) genes.

Conclusions:

PC should be considered as a differential diagnosis of PHPT in the pediatric population, even in the presence of mild hypercalcemia.

1. Introduction

Primary hyperparathyroidism (PHPT), characterized by hypercalcemia due to excessive parathyroid hormone (PTH) secretion, is now recognized as the third most common endocrine disorder in the adult population (1), with a prevalence of 8 in 1000 in the general population (2). On the contrary, PHPT is a very rare condition in the pediatric population, with an estimated incidence of 2 - 5 cases per 100,000 people (1, 3). Furthermore, young patients with PHPT usually present with clinical signs and symptoms of hypercalcemia, including fatigue, anorexia, vomiting, skeletal disorders, and renal stone, whereas adult patients are often asymptomatic (1, 4).

Approximately 80% of pediatric PHPT cases result from PAs (5). Other causes include different genetic syndromes, namely multiple endocrine neoplasia 1 (MEN1), MEN 2A, hyperparathyroidism-jaw tumor syndrome (HPT-JT), and familial isolated hyperparathyroidism (FIHP) (6). PC is a rare cause of PHPT (< 1%), with only a few case reports describing this carcinoma in pediatric PHPT cases (5-8). The challenging issue is to distinguish between PA and its rare malignant counterpart. The diagnosis of carcinoma is often made histologically, after a local recurrence, or when a distant metastasis is present (2, 5, 9).

In this report, we described a young female who presented with a history of progressive limping and was eventually diagnosed with PHPT due to PC.

2. Case Presentation

A 15-year-old girl presented with a history of progressive limping for 8 years. Another symptom was diffuse bone pain for 3 years. Family and drug histories were unremarkable. On physical examination, a large, firm, and non-tender mass was palpable in the right thyroid lobe. Left hip range of motion was limited in all directions, both actively and passively, and tenderness was present on left femoral head palpation. The rest of the physical examination was normal.

Biochemical tests were performed and initial laboratory test results were as follows: serum calcium: 10.8 mg/dL (range: 8.5 - 10.5 mg/dL); phosphorus: 2.4 mg/dL (range: 2.9 - 5.1 mg/dL); iPTH: 2876 pg/mL (range 15 - 65 pg/mL); 25-hydroxy vitamin D3: 13.76 ng/mL (range 15 - 65 ng/mL); thyroid-stimulating hormone (TSH): 3.11 µIU/mL (range 0.51 - 4.34 µIU/mL); and alkaline phosphatase (ALP): 7410 IU/L (range: 180 - 1200 IU/L). While PHPT could be associated with other endocrinopathies, the complementary evaluations, such as insulin-like growth factor-1 (IGF-1) and prolactin measurements were done (Table 1).

Table 1.

The Patient’s Biochemical Tests

Basic Lab ResultsResultReference Range
Calcium, mg/dL10.88.5 - 10.5
Phosphorus, mg/dL2.42.9 - 5.1
Alkaline phosphatase, IU/L7410180 - 1200
iPTH, pg/mL2876.015 - 65
BUN, mg/dL3.75.5 - 23
Urea, mg/dL830.8 - 48.1
Creatinine, mg/dL0.540.5 - 1.4
25-hydroxy vitamin D3, ng/mL13.67< 10: deficient; 10 - 30: insufficient; 30 - 100: sufficient; 100 - 150: overdose; > 150: intoxication
TSH, µIU/mL3.110.51 - 4.34
Random urine calcium, mg/dL15.700.5 - 35.7
Random urine creatinine, mg/dL69.8116 - 327
Random urine Ca/Cr ratio0.225< 0.14 : Normal; > 0.2 : Hypercalciuria
Insulin-like growth factor 1 (IGF1), ng/mL15312 – 15 y: 115.4 - 498.2
Prolactin, µIU/mL414.40102 - 496

The plain pelvic radiography demonstrated a left femoral neck fracture. Spine radiography displayed wedge fractures at thoracic and lumbar spine levels (Figure 1). Bone mineral density (BMD) showed low bone density (lumbar spine's Z-core: -3.7). According to the above-mentioned test results, including elevated PTH, borderline high serum calcium, decreased phosphorus, and elevated ALP, primary hyperparathyroidism was considered as the most probable diagnosis.

A, Pelvic plain radiography shows femoral neck fracture; B, thoracic and lumbar spine pain radiography demonstrated vertebral wedge fracture.
A, Pelvic plain radiography shows femoral neck fracture; B, thoracic and lumbar spine pain radiography demonstrated vertebral wedge fracture.

Dual-phase sestamibi scintigraphy was performed for the patient after intravenous (IV) injection of 540 MBq of 99mTc-MIBI. The early scan images (at 20 minutes) revealed high thyroid uptake in the right lobe with a suppressive effect on the left side. Increased radiotracer uptake was seen in the right lobe without proper washout on delayed images, which was higher and larger than is expected with PAs (Figure 2A). A thyroid scan was also done two days later, after IV injection of 185 MBq of 99mTc from the anterior view to rule out a thyroid nodule. This scan revealed a focal decreased uptake in the upper pole of the right lobe, which was smaller compared with the finding of the parathyroid scan (Figure 2B). The discrepancy between the two scans led to further investigation into the underlying pathology. Neck ultrasound revealed an enlarged right thyroid lobe compatible with intra-lobar necrosis and echogenic regions with the approximate size of 20 mm compatible with the parathyroid gland (Figure 3A and B).

A, Parathyroid sestamibi scintigraphy in early (20 min) and delayed (1 and 3 hr.) phases; B, thyroid scintigraphy two days after parathyroid scan
A, Parathyroid sestamibi scintigraphy in early (20 min) and delayed (1 and 3 hr.) phases; B, thyroid scintigraphy two days after parathyroid scan
A, Ultrasonography shows large thyroidal nodule; B, intra nodular hyper and hypoechogenesity
A, Ultrasonography shows large thyroidal nodule; B, intra nodular hyper and hypoechogenesity

The patient was referred to an experienced surgeon for neck exploration and parathyroidectomy. She underwent open surgery. The parathyroid mass had infiltrated to the surrounding thyroid tissue; hence, right thyroidectomy, isthmectomy, and right inferior parathyroidectomy were performed. The remaining parathyroid glands were examined during the operation and were normal. She experienced hungry bone syndrome postoperatively, which was managed appropriately. Finally, serum calcium and iPTH levels decreased to a level of 8.7 mg/dL (8.5 - 10.5 mg/dL) and 24 pg/mL (15 - 65 pg/mL), respectively. The operative phosphorus level was 2.3 mg/dL.

Gross histopathologic examination revealed a well-defined cream-colored mass measuring 2.5 × 1.5 × 1.0 cm. IHC helped with the confirmation of diagnosis (Figure 4).

Parathyroid gland and right thyroidal lobe
Parathyroid gland and right thyroidal lobe

Histologic examination showed uniform chief cells presenting as nodules and sheet growth with proliferated blood vessels that were separated by a broad fibrous capsule from the adjacent thyroid tissue. The tumor had invaded the capsule and blood vessels. IHC staining for CD34 confirmed vascular invasion. IHC was also diffusely positive for CK in the tumor and tumor cells attached to endothelial cells. Ki67 was also positive in 2% - 3% of tumor cells. However, other markers, such as CD45, thyroid transcription factor 1 (TTF-1), and Pax5 were negative (Figure 5A-G).

A, Vascular invasion in parathyroid carcinoma. Tumor cluster within the blood vessel lumina. (H & E, original magnification 200×); B, proliferated blood vessels in parathyroid carcinoma (H & E, original magnification 400×); C, uniform tumor cells presented as sheet (H & E, original magnification 200×); D, broad fibrous capsule invaded by tumor cells; E, nodules of tumor cells and fibrous band (H & E, original magnification 400x); F, CK positive in tumoral cells (IHC, original magnification 200×); G, CD34 is positive in blood vessel endothelium (orange arrow) which invaded by tumor cells (black arrow) (IHC staining, original magnification 200×).
A, Vascular invasion in parathyroid carcinoma. Tumor cluster within the blood vessel lumina. (H & E, original magnification 200×); B, proliferated blood vessels in parathyroid carcinoma (H & E, original magnification 400×); C, uniform tumor cells presented as sheet (H & E, original magnification 200×); D, broad fibrous capsule invaded by tumor cells; E, nodules of tumor cells and fibrous band (H & E, original magnification 400x); F, CK positive in tumoral cells (IHC, original magnification 200×); G, CD34 is positive in blood vessel endothelium (orange arrow) which invaded by tumor cells (black arrow) (IHC staining, original magnification 200×).

Whole exome sequencing (WES) study was done for the assessment of familial hyperparathyroidism and MEN1. The genetic study demonstrated no mutation in CDC73 and menin genes. However, there was an incidental mutation in the breast cancer 1 (BRCA1) gene.

We performed an extensive search using different databases, including Medline, PubMed, Scopus, ScienceDirect, and Google Scholar to find all published cases of PC in children and adolescents. We used the following combination of keywords: parathyroid carcinoma or parathyroid cancer or parathyroid neoplasm or parathyroid malignancy, and pediatrics or child or adolescent or boy or girl. We could find 16 papers reporting 17 cases of pediatric PC from 1972. Table 2 summarizes the published papers.

Table 2.

Published Cases of Pediatric Parathyroid Carcinoma From 1972 to 2020

Case NoReferenceYearAge/SexFH of HPTSymptoms and Signs Ca/iPTH(before initial operation)LocationSize, mmMetastasis/RelapseFollow-upIHC/Genetic Analysis
1(9)197216/FNAAnorexia, vomiting, renal calculi15.6/2000Left upper parathyroid gland and thymusNAYes/noNormocalcemiaNA/NA
2(9)197713/FNABone pain, weakness, neck mass15.6/NARight upper parathyroid glandNAYes lung/yesHypercalcemiaNA/NA
3(7)197313/NANANANANANANANANA/NA
4(10)198415/MNAEpigastric pain, nausea, vomiting, lethargy, seizures, pancreatitis16.0/800Left lower parathyroid gland20 × 20NoNANA/NA
5(11)199314/MYesBone disease,myopathy, polyuria, polydipsia13.2/3328Right lower parathyroid gland30 × 35NoNormocalcemiaNA/NA
6(12)199915/MNANeck mass, vomiting, fatigue, weight loss20.7/358Left lower parathyroid gland30 × 20 × 10NoNormocalcemiaNA/NA
7(13)20028/FYesRenal calculi, lethargy, anorexia, neck mass14.3/190Left lower parathyroid15 × 10 × 10NoNormocalcemiaNA/MEN1 analysis negative
8(14)200910.5/MYesanorexia, fatigue, and knee pain15.5/300Ectopic (mediastinal)NALocal invasion to thymusNormocalcemiaNA/NA
9(15)201114/FNoPolyarthralgia, myopathy, deformities, depression14.3/2792Right lower parathyroid gland25NoNormocalcemiaNA/NA
10(16)201213/FNoAsymptomatic neck mass12/8638Right thyroid35 × 30 × 20Yes/LungHypercalcemiaNA/NA
11(17)201211/MNALegs’ BowingNA/1630Right lower parathyroid glandNANoNormocalcemiaNA/NA
12(18)201510/FNAAbdomeninal pain, difficulty in walking, extremities deformities12.2/2217Left parathyroid glandNANANANA/NA
13(5)201613/FNoAnorexia, fatigue, vomiting, anhedonia, back pain,polydipsia, weight loss, Pathological fracture, renal calculi20.5/1068Neck NAYes, cervical nodes, lungHypercalcemiaNA/heterozygous partial deletion of CDC73
14(8)201614/FNoPathological slipped capital femoral epiphysis, neck mass13.4/1013Left lower parathyroid gland33 × 30 × 13NoNoHRPT2/CDC73 germline mutation
15(19)201915/FNoFatigue, fever, bone pain, neck mass15.7/1170Right upper parathyroid gland38 × 18 × 17NoNormocalcemicMenin mutation:negative Galectin3,P TH were positive, Ki67 was 12.5%
16(6)201916/MNoNon-healing fracture, neck mass, short stature, calculi 15.61/2028Right lower parathyroid gland30 × 30 × 2.5NoNASparse parafibromin nuclear staining/heterozygous deletion of CDC73
17(20)202013/FNobilateral genu varum and signs of hip impingement15.4/980Right lower parathyroid gland23 × 13 × 16NoNormocalcemicNegative
1815 Our casea202015/FNoLimping, bone pain, neck mass, hip fracture10.8/2876Right lower parathyroid gland25 × 15 × 10NoNormocalcemiaKi67 positive in 2 - 3 %, CK And CD31/BRCA1 was an incidentally finding

According to these reports, the male to female ratio was 0.6. The youngest and oldest patients were 8 and 16 years old, respectively. The most common initial presenting symptoms were related to hypercalcemia, including anorexia, vomiting, polyuria, polydipsia, fatigue, bone pain, and renal calculi. Sixty percent had a palpable neck mass. Nearly 50% had skeletal involvement, including fracture and deformity. Only three patients had experienced weight loss. Pancreatitis was a rare condition diagnosed in one case. Nearly 20% had metastasis, most common sites were lung and cervical lymph nodes, and all cases with pulmonary involvement had experienced relapse and hypercalcemia after the initial operation. The range of serum calcium and iPTH was 12 - 20.7 mg/dL and 300 - 8638 pg/mL, respectively. IHC had been reported in two cases, which were both positive for parafibromin (6). Three cases had deletion mutation of CDC73, and another case was negative with regard to menin gene mutation. Three patients had a positive family history of primary hyperparathyroidism. There was no predominant tumor location site at the neck.

3. Discussion

Here, we presented an extremely rare endocrine disease. The aforementioned case was a girl who presented with longstanding limping and bone pain. The complementary examination revealed a palpable right neck mass and left hip fragility fracture.

Little evidence exists with regard to PC in pediatrics compared with adults; therefore, our review is mostly based on adult PC. This review article focused on the epidemiology, etiology, pathogenesis, clinical presentation, diagnosis, management, and prognosis of PC.

The estimated incidence of PHPT in children is 2 - 5 cases in 100,000. PC is responsible for less than 1% of the PHPT causes (1-3). It is considered an extremely rare malignancy among endocrine malignancies. The estimated incidence and prevalence of PC are 0.015 per 100,000 population and 0.005%, respectively (21). In most adult studies, PC accounts for less than 1% of PHPT cases; however, in Japan, Europe, and the United States, it is responsible for 0.017% to 5.2% of adult patients with PHPT (21, 22). There appears to be a female predominance; nonetheless, the reported cases of PC in the pediatric population are limited.

According to a meta-analysis, the pathophysiology of PHPT is different in adults and children. This may be due to increased sensitivity to iPTH at the level of target tissues and decreased negative feedback of the parathyroid gland to calcium (1).

The exact etiology and pathogenesis of PC are unclear. PC occurs sporadically. Although neck irradiation could be a risk factor for PAs, its role is less clear in PC (23). End-stage renal disease (24), underlying parathyroid hyperplasia, or adenoma are the uncommon causes (25).

Another form of PC is familial, which can occur in HPT-JT and FIHP. Besides, MEN1 and MEN 2A are rare causes of PC (6, 23).

A genetic marker associated with PC is the CDC73 gene that encodes parafibromin. It is related to HPT-JT and FIHP and is found in up to 80 % of sporadic PC cases. Other genetic markers include cyclin D1, retinoblastoma 1 (RB1), and BRCA2, which are abnormally expressed in some parathyroid cancers (26). Mutated MEN1 and rearranged during transfection (RET) genes have been shown in MEN1 and MEN2A syndromes, respectively. Yet, less than 0.01% of MEN1-related parathyroid tumors are malignant (27).

Of note, most cases of PC are functional and almost all of them are symptomatic (e.g. polyuria, polydipsia, anorexia, vomiting, weakness, weight loss, and neurocognitive signs or symptoms related to hypercalcemia and elevated PTH) (23). The review of the pediatric population with benign PHPT showed that children and adolescents are more often symptomatic than adults at the time of diagnosis. Besides, they present with more end-organ manifestations compared with adults (7). Nonfunctional PC is an atypical presentation and accounts for less than 10% of PCs. It often presents as a palpable cervical mass that can compress the surrounding structures and cause hoarseness and/or dysphagia (28).

Although benign PA is the most common cause of PHPT and it is difficult to distinguish between carcinoma and adenoma prior to parathyroidectomy, some remarkable clinical and biochemical clues can guide the clinician to suspect PC as a cause of PHPT. These include male gender, an average age of 50 years at the time of diagnosis (28), and serum calcium greater than 14 mg/dL or 3 - 4 mg above the upper limit of the normal range. PTH level is more than twice and is often 3 - 10 times higher than the normal limit in PC; however, it is less than twice the normal upper limit in PA. Clinically, PC patients often have both kidney and bone manifestations at diagnosis (i.e., nephrolithiasis, renal failure, renal colic, bone pain, pathological fractures, and osteitis fibrosa cystica) (23). Significant elevation in total serum alkaline phosphatase, which is a marker of synchronous skeletal and kidney involvement, is often seen in patients with HPT/JT and/or cases belonging to a family with HPT/JT syndrome. Ultrasonographic features of an extrathyroidal neck lesion, invasion to the adjacent tissue, local invasion, and metastases found intraoperatively or on parathyroid sestamibi scintigraphy and/or on computed tomography scans preoperatively, unilateral vocal cord palsy and/or a palpable neck mass, and concomitant hypercalcemia are other signs of PC (29). Pancreatitis, anemia, and peptic ulcers are other rare manifestations (23).

Studies have shown that human chorionic gonadotropin (hCG) and its malignant hyperglycosylated isoform are found in serum and urine of PC patients. However, further studies should be done to establish the clinical value of these findings (28).

Surgery is the treatment of choice, and the best method is en bloc excision with ipsilateral thyroid lobectomy and removal of involved lymph nodes; however, en bloc excision is only performed in 12% of cases (23). During the surgery, it is advised to examine all four glands because synchronous involvement of glands has been shown in some studies (30).

Survival depends on the presence of a variety of factors, including the type of surgery, (i.e., parathyroidectomy versus radical resection [en bloc]), high serum calcium and/or intractable hypercalcemia, local recurrences and/or metastases, CDC73 mutation, and/or loss of parafibromin staining or calcium sensing receptor (CaSR) protein, and finally, nonfunctioning PC, which are all poor prognostic factors for survival (23). Hypercalcemia-related complications are the main cause of mortality (28).

In conclusion, our case was a sporadic PC with fracture, which is really unique with regard to the long duration of symptoms and mild hypercalcemia. Despite a high level of PTH (44 times above the upper limit of normal), the patient had mild hypercalcemia. This might be due to low bone mass and/or low calcium intake. The results of this study suggest that the size of the tumor, the involvement of surrounded soft tissue by the tumor, very high serum level of iPTH, and ALP may be helpful to predict PC in children with PHPT before the primary operation.
