The Effect of Anterior Cruciate Ligament Reconstruction Technique on Graft Signal Intensity at Mid-Term Follow-Up

1. Background

In everyday practice it is of great importance to understand the etiology and significance of increased graft signal intensity (IGSI) in order to adequately interpret imaging findings. Early studies described intact anterior cruciate ligament (ACL) graft as having low graft signal intensity (GSI) (1). However, several studies in the past two decades have shown that intact grafts may show variable degrees of IGSI (2-4). In the literature, various underlying causes are associated with IGSI; graft impingement (5), imaging artifacts (6), incomplete maturation of the graft (3), enlargement of the drilling tunnels (7), and degenerative changes (4).

No study has yet evaluated the impact of anterior cruciate ligament reconstruction (ACL-R) technique on IGSI.

2. Objectives

The aim of our study was to find out if ACL-R technique affects GSI at mid-term follow-up. Our hypothesis was that GSI is affected by the ACL-R technique.

3. Patients and Methods

3.1. Study Design and Patients

The national medical ethics committee approved the study and written informed patient consent was obtained for this study. From 2008 to 2010, the orthopedic department at our institution gradually switched from the transtibial (TT) ACL-R technique to anteromedial (AM) portal ACL-R technique. In the period from January 2008 until October 2009, 107 patients underwent TT with RIGIDfix fixation and in the period from November 2008 until July 2010, 132 patients underwent AM with Endobutton fixation. Based on the review of clinical notes, 35 patients from each group met the following study inclusion criteria: (1) autologous quadruple stranded semitendinosus-gracillis graft (STGR), (2) no history of prior knee surgery, (3) no history of total meniscectomy or concomitant collateral ligament disruption, (4) 16 - 45 years at operation, (5) sports activity of at least four on Tegner scale prior to the ACL rupture, (6) no readmissions or records of knee related problems after ACL-R and (7) no MR contraindication. Fifty patients were successfully contacted; their demographic characteristics are shown in Table 1. Patients were divided into two groups, patients who underwent TT with RIGIDfix fixation (group 1, n = 25) and patients who underwent AM with Endobutton fixation (group 2, n = 25). Range for the time from ACL-R to MR examination was from 52.1 to 87.0 months.

3.2. Surgical Technique

At ACL-R, arthroscopic examination was performed to confirm ACL rupture. In all patients, single-bundle, quadruple stranded STGR auto-grafts were used. In both groups, tibial tunnel was drilled at a sagittal angle of 60° to the tibial plateau with the use of tibial drill guide (Mitek, Johnson & Johnson, Norwood, MA, USA). The graft was fixed by using Milagro interference screw (DePuy Mitek, Raynham, MA, USA).

In the TT group, the knee was positioned in 90° flexion and cannulated end-cutting head design reamer (Mitek, Johnson & Johnson, Norwood, MA, USA) was introduced transtibially drilling the femoral tunnel to the depth of 25 to 30 mm. In the femoral tunnel, the graft was fixed by using RIGIDfix (Mitek, Johnson & Johnson, Norwood, MA, USA).

In the AM group, the knee was positioned in 120° flexion and cannulated end-cutting head design reamer (Mitek, Johnson & Johnson, Norwood, MA, USA) was passed through the AM portal drilling the femoral tunnel to the depth of 25 to 30 mm. In the femoral tunnel, the graft was fixed by using Endobutton (Smith & Nephew Endoscopy, Andover, MA, USA).

3.3. Clinical Assessment

Patients’ sport activity was evaluated according to Tegner activity scale at three different time points (prior to the injury, at ACL-R and at MRI examination) (8). At ACL-R, patients were asked to evaluate their sport activity prior to the injury and as currently active. At MRI examination, the patients were asked to evaluate their current sport activity. To evaluate patients’ perception of knee related problems, the international knee documentation committee (IKDC) questionnaire was presented to the patients at MRI examination (9).

3.4. MRI Protocol

MRI was performed with a 3.0 T imager (Magnetom® Trio, Siemens, Erlangen, Germany) by using an 8-channel transmit-receive knee coil (Invivo, Gainesville, FL, USA) in the supine position.

Imaging sequences included proton density (PD) turbo spin echo (TSE) fat saturation (FS) images in three planes (2400/32 [repetition time (TR) msec/echo time (TE) msec], 15 cm field of view [FOV], 3 mm/1 mm [slice thickness/interslice gap], 384 × 384 matrix, 150° flip angle, 2 signals acquired).

3.5. MRI Analysis

Qualitative image analysis and quantitative image measurements were performed on a Leonardo® workstation (Siemens Medical Solutions, Erlangen, Germany).

The following MRI findings were evaluated:

1. Graft failure was evaluated as ACL graft being ruptured or preserved. A graft was considered ruptured when no intact fibers were seen and fluid signal was interposed between the ends of graft fibers (10). Patients with graft failure were not included in further analysis.

2. Graft impingement was evaluated as the tibial tunnel being placed partially or completely anterior to the most anterior edge of the femoral notch roof, corresponding to the Blumensaat line (10).

3. Graft signal intensity (GSI) was analyzed on PD FS images. ACL graft was divided into two portions – intraarticular portion (IAP) and intraosseous portion (IOP). IAP was further divided into two parts – proximal and distal. The intraosseous portion was further divided into two parts – femoral (fIOP) and tibial (tIOP). IGSI was evaluated on PD FS images as present (increase of signal intensity within the substance or absence) (4). IGSI was subclassified as comprising less than 25%, 25% - 50%, or more than 50% of the maximal cross sectional area of the graft (4).

4. Graft orientation of the IAP was evaluated on the coronal and sagittal PD FS images and was defined as the angle between the long axis of the graft and the tibial plateau – the sagittal graft angle (SGA) and the coronal graft angle (CGA) (11).

5. The position of the drilling tunnels was evaluated on coronal and sagittal PD FS images. The position of the femoral tunnel was measured in both planes as the angle between the axis of the femoral tunnel and the tibial plateau. The same approach was used to measure the position of the tibial tunnel.

3.6. Statistical Analysis

A Mann-Whitney test was used to compare groups according to Tegner scale. Wilcoxon signed-rank test was used to evaluate Tegner scale according to different time points. Chi-square test was used to compare both groups according to the preservation of ACL graft and evaluation of the presence of IGSI. A Student two-tailed t-test was utilized to compare groups with respect to the continuous variables. To assess intra-rater reliability the evaluated MRI findings were assessed twice in group 1 by the same operator; the reliability for continuous variables was expressed with interclass correlation coefficient (ICC) and the reliability for categorical variables was expressed with Cohen’s kappa (κ). Continuous variables were expressed as mean ± SD and categorical values were expressed as median. Significance was set at P < 0.05. The post-hoc power of the primary study endpoints are π = 0.77 for the GSI evaluation of the IAP and π = 0.90 for the GSI evaluation of the IOP. Statistical analysis was performed with SPSS v.17.0 (SPSS Inc., Chicago, Ill, USA).

4. Results

4.1. Clinical Assessment

There was no difference in Tegner activity scale between the study groups prior to the injury, at ACL-R and at MRI examination (P = 0.41; P = 0.82 and P = 0.88, respectively). Tegner activity scale in group 1 was six prior to the injury, four at ACL-R and six at MRI examination. Tegner activity scale in group 2 was seven prior to the injury, four at ACL-R and six at MRI examination.

Patients in group 1 and 2 showed similar mean IKDC subjective knee score at MRI examination (82.5 ± 17.3 vs. 81.5 ± 16.1, respectively; P = 0.84).

4.2. MRI Findings

Graft failure – Six (12.0%) patients had ruptured ACL graft. Patients from group 1 tended to have lower graft failure rates than patients from group 2 [one (4.0%) patient vs. five (20.0%) patients; P = 0.08].

Graft impingement – Graft impingement was seen only in one patient in each group. Very good intra-rater reliability with κ = 0.96 was observed for graft impingement.

GSI – Group 2 showed higher rates of IGSI of the IAP and fIOP (Table 2) (Figures 1 and 2). The subclassification of the IGSI is shown in Table 3. Fifteen (36.6%) patients had IGSI of the IAP, 35 (85.4%) had IGSI of the IOP and only 4 (9.8%) showed low GSI of the entire graft course. The presence of IGSI showed very good intra-rater reliability with κ = 0.96, however the subclassification of IGSI showed moderate intra-rater reliability with κ = 0.79.

Sagittal proton density (PD) fat saturation (FS) images in (A) a 49-year-old man from group 1 and (B) a 27-year-old woman from group 2 show the difference in the signal intensity of the intraarticular and the tibial intraosseous portion of the anterior cruciate ligament (ACL) graft.

Figure 1.

Sagittal proton density (PD) fat saturation (FS) images in (A) a 49-year-old man from group 1 and (B) a 27-year-old woman from group 2 show the difference in the signal intensity of the intraarticular and the tibial intraosseous portion of the anterior cruciate ligament (ACL) graft.

Axial proton density (PD) fat saturation (FS) images in (A) a 45-year-old man from group 2 and (B) a 24-year-old man from group 2 show the difference in the signal intensity of the femoral intraosseous portion of the anterior cruciate ligament (ACL) graft.

Figure 2.

Axial proton density (PD) fat saturation (FS) images in (A) a 45-year-old man from group 2 and (B) a 24-year-old man from group 2 show the difference in the signal intensity of the femoral intraosseous portion of the anterior cruciate ligament (ACL) graft.

Graft orientation of the IAP – Both groups showed similar mean position of the CGA. However, the SGA was more horizontal in group 2 than in group 1 (Table 4). The intra-observer ICC of the CGA and SGA graft measurements were 0.86 and 0.88, respectively.

The positions of the drilling tunnels – Both groups showed similar mean positions of the tibial tunnel and the femoral tunnel in the sagittal plane (Table 4). Femoral tunnel in the coronal plane was positioned more horizontally in group 2 than in group 1 (Table 4). The intra-observer ICC for the femoral tunnel in the coronal and sagittal plane were 0.92 and 0.88, respectively.

Statistical results of the relationships – The relationships between demographic characteristics, continuous variables of the MRI findings, clinical outcome and GSI were performed. In each of the studied graft portions, one significant effect was found (Table 5). Patients with IGSI of the IAP showed more horizontal position of the coronal tibial tunnel (15 vs. 29 patients, 69.6° ± 7.8° vs. 58.9° ± 20.7°; P = 0.02). Patients with IGSI of the fIOP showed more horizontal position of the coronal femoral tunnel (29 vs. 15 patients, 52.0° ± 5.4° vs. 62.3° ± 9.4°; P < 0.01). Patients with IGSI of the tIOP showed more horizontal position of the sagittal tibial tunnel (24 vs. 20 patients, 60.7° ± 7.8° vs. 65.6° ± 7.1°; P = 0.03).

5. Discussion

In the present study, MRI graft measurements and clinical outcome were undertaken in order to compare ACL-R techniques and to find out whether any relationship exists with GSI. The most important finding of our study was the difference in IGSI between study groups.

Causes of graft failure are multifactorial with the most important being trauma, technical error and failure of graft incorporation (12). It has not yet been determined which fixation method and what position of the drilling tunnels offers a lower rate of graft failure (12, 13). Graft failure rate in our study was 12% and the result is comparable with previous papers, which reported graft failure of quadruple stranded STGR in 4% - 15.3% (13, 14). Although short of statistical significance, group 2 tended to have higher rate of graft failure than group 1.

Comparing study groups in respect to graft position and clinical evaluation, similar findings were found in previously reported papers studying TT and AM (15, 16). The sagittal graft position of the IAP and the coronal position of the femoral drilling tunnel in group 2 were found to be more horizontal than in group 1. There were no differences in Tegner activity scale and IKDC score between the study groups. However, significant difference in the rate of IGSI between the study groups was observed.

GSI in the early postreconstruction period has been well studied, however few studies evaluated the GSI at mid- or long-term follow-up (2, 4, 17). In short-term studies, the entire course of the graft has been studied and it was shown that IGSI is a dynamic process of healing and by 2-years postreconstruction, the graft should resume uniformly low GSI on MRI (18, 19). Saupe et al. evaluated IAP of the graft 4 to 12 years after ACL-R and found IGSI on intermediate-weighted images in 70% and on T2-weighted images in 64% of the patients. However, no clinical or functional correlation with IGSI was found (4). Horton et al. evaluated IAP of the graft 6 months to 10 years after ACL-R and found IGSI on PD-weighted images in 40% of the patients (17). Biercevicz et al. showed that the median GSI significantly contributed to the predictions of functional and patient-orientated outcome at 5-year follow-up (2). Furthermore, previous studies have shown better knee performance and surgical outcome in grafts with lower GSI (2, 20). In our study, IGSI of the IAP was observed in 36.6 %, and only 9.8% of patients showed low GSI of the entire graft course. Moreover, there was a statistically significant difference between the study groups in IGSI of the IAP. However, there was no difference in the clinical outcome between the study groups and no relationship was found between IGSI and clinical outcome.

We found no previous studies evaluating IGSI of the IOP at mid- or long-term follow-up. In our study, IGSI of the IOP was observed in 85.4% of the patients. Group 2 showed significantly higher rates of IGSI of the fIOP. However, there was no difference between groups in IGSI of the tIOP. Previous studies showed a difference in the healing process between the drilling tunnels with tendon-to-bone healing being faster in the tibial than the femoral tunnel. However, at our follow-up time, this process should have already subsided (2, 21). Farshad-Amacker et al. observed that recent trend toward ”anatomic” femoral and tibial footprints affects signal properties of the graft (22). They described prolonged hyperintensity in the delayed perioperative period, however uncertain if IGSI is due to plastic deformation or higher tension of the graft (22). Our results suggest there appears to be a difference in IGSI between the tibial and femoral tunnel, which may be attributed to the femoral tunnel positioning and graft fixation.

A statistically significant effect was found between the coronal position of the tibial tunnels and IGSI of the tIOP in our study. Previous studies have shown that the angle of the femoral and tibial tunnels strongly affects graft tension (23, 24). Lower graft tension is obtained with femoral and tibial tunnels with angles of 60° (23, 24). Patients in our study showed IGSI of the IAP when coronal tibial tunnel was positioned closer to 60° and showed low GSI when the coronal tibial tunnel was positioned closer to 70°. Moreover, statistically significant effect was found between the coronal position of the femoral tunnel and IGSI of the fIOP. This result has to be interpreted with caution, since patients from group 2 showed higher rates of IGSI of the fIOP and had femoral tunnel positioned more horizontally than group 1. It should not be neglected that this result could as well be attributed to graft fixation.

There were some limitations in the study. The first and likely most important limitation was that different femoral fixation and different femoral drilling techniques were used between groups. The findings of our study need to be interpreted critically to what degree the findings could be attributed to a difference in femoral fixation or difference in femoral tunnel drilling. The second limitation of our study was that clinical and radiological characteristics were reviewed retrospectively and no objective assessment of the knee was performed with lack of surgical conformation of the findings in the study. Another limitation of our study was the consequence of potential study-selection bias with patient cohorts being designed with presumption of good clinical outcome and not seeking medical reassessment. However, the cohort study is likely representative of a spectrum of postreconstruction findings in patients at mid-term follow-up after ACL-R.

In conclusion, IGSI can be seen on PD FS images in the majority of patients after ACL-R at mid-term follow-up. Our study demonstrates that graft tunnel positioning and graft fixation device may influence GSI.
