Cloning and Expression of Poly 3-Hydroxybutyrate Operon Into Escherichia coli

1. Background

Petrochemical plastics have been developed into a major industry and are resistant to natural and chemical breakdowns (1). Nondegradable plastic causes environmental problems. Alternatively, bioplastics are polyesters synthesized by bacteria under unbalanced growth conditions (2). Poly Hydroxyalkanoate (PHA), the most known source of bioplastics, is a potential candidate for substitution of petrochemical plastics, because of its biodegradability properties. Biodegradable polymers are made from renewable resources, and thus do not lead to depletion of finite resources (3). These biopolymers have many desirable physical and chemical properties of conventional synthetic polymers (4). To this point, high production costs have limited the use of biopolymers; however, if these costs be reduced, there would be a widespread economic interest (5).

PHAs are generally in the form of (R)-β-hydroxyl fatty acids (6). Poly 3-Hydroxybutyrate (PHB) is the most common PHA. The PHB biosynthetic pathway includes three enzymatic reactions, catalyzed by three distinct enzymes. In the first reaction, b-ketoacyl CoA thiolase (encoded by the phbA gene) condenses two acetyl-CoA molecules into acetoacetyl-CoA. The second reaction is the reduction of acetoacetyl-CoA to (R)-3-hydroxybutyryl-CoA by an acetoacetyl-CoA dehydrogenase (encoded by the phbB gene). Finally, P (3HB) polymerase (encoded by the phbC gene) polymerizes the (R)-3-hydroxybutyryl-CoA monomers into PHB (7). Only a few bacteria such as Alcaligenes latus, Bacillus megaterium, Ralstonia eutropha, and Pseudomonas oleovorans have been used for the production of PHA. R. eutropha is a non-spore-forming, Gram-negative bacterium and the most common bacterium for PHA production (2). There are also some limitations associated with the use of natural PHA producers. Natural PHA-producing bacteria usually harbor native machinery for polymer degradation and are often hard to lyse, making the recovery of PHA difficult (2). Therefore, the use of recombinant bacteria is more useful in production of PHA. The use of recombinant Escherichia coli for PHA production is beneficial in some points as fast growth, high cell density, ability of using several cheap carbon sources, and easy purification (8).

2. Objectives

Our objective was cloning and expression of the phb operon of R. eutropha H16 to E. coli BL21, and then PHB production from the recombinant bacteria.

3. Materials and Methods

3.1. Bacterial Strains, Plasmids and Culture

Dried culture of R. eutropha H16 (DSM 428) was purchased (DSMZ, GmbH). R. eutropha was cultured on nutrient broth (8% w/v) at 30°C for 24 hours. Nutrient agar containing 5 g peptone, 3 g meat extract and 15 g agar was dissolved in 950 mL distilled water; the final pH was adjusted at 7.3. Distilled water was added up to 1 L and then the final solution was autoclaved. The E. coli BL21 (DE3) was obtained from Pasteur Institute of Iran. These strains were cultured on Luria-Bertani (LB) medium (9) at 37°C for 16 hours. The pET-28a expression vector was purchased from Pasteur Institute, Iran.

3.2. Amplification

The total genomic DNA of R. eutropha was extracted (9). The desired fragment (3851 bp for phbCAB genes) was amplified by designed primers which possessed cutting sites on their 5' ends for BamHI and HindIII restriction enzymes. The primers were designed by authors. The sequence of PHB BamHI-forward primer was GCCGGATCCATGGCGACCGGCAAA and the one for PHB HindIII-reverse primer was GCCAAGCTTTCAGCCCATATGCAGGCC. The Phusion^® Master Mix kit with GC Buffer (Bio Lab, New England) was used for amplification of this fragment. The thermo-cycler program was as follows: 98°C for three minutes, then 30 cycles of 98°C for 15 second, 65°C for one minute, 72°C for two minutes, and Finally 72°C for 10 minutes.

3.3. Production of Recombinant Vector

The PCR product and pET-28a vector were digested by Bam HI and Hind III restriction enzymes at 37°C for 16 hours and they were purified from the gel. Purification was performed according to Silica Bead DNA gel extraction kit (Fermentas, CA). Afterwards, ligation of the PCR product and vector was performed by T4 ligase at 16°C for 16 hours.

3.4. Bacterial Transformation and Restriction Digestion

Competent cells were prepared using CaCl₂ (9). The transformation was performed according to Green and Sambrook’s guideline (9). To prove the successful cloning of PCR products, the plasmid DNA was extracted from some bacterial clones and digested with Bam HI and Hind III (Fermentas, CA) overnight at 37°C and the resulted fragments were loaded on 1% agarose gel.

3.5. Expression Study

The LB medium (supplemented with 30 μg/mL Kanamycin), inoculated with an overnight culture of recombinant cells, was incubated at 37ºC until reaching the optimized optical density. Afterwards, isopropyl l-beta-D-thiogalactopyranoside (IPTG) was added at a final concentration of 0.4 mM and the incubation continued for eight hours at 37ºC with shaking at 150 rpm. The cells were harvested by centrifugation at 5000 rpm for 10 minutes.

3.6. Poly 3-Hydroxybutyrate Staining

A thin bacterial smear was made on the clean glass slide. The smear was air-dried and stained with a 3% Sudan Black B solution (3 gram w/100 mLv in 70% ethanol, Sigma) for 10 minutes. The smear was washed and air-dried. The sample was stained with Safranin (5% w/v in distilled water, Sigma) for 10 seconds, washed again with distilled water, and dried and observed under oil immersion lens (10).

4. Results

In R. eutropha, the lengths of phbC, phbA and phbB genes were respectively 1770 bp, 1182 bp and 741 bp. A pair of primers was designed for amplifying the phbCAB genes, which include the beginning of the phbC gene to the end of the phbB gene and the HindIII and BamHI restriction site sequence was added to the ends of the primers. PCR was accomplished by these primers and the desired fragment was amplified. The PCR product was checked by 1% agarose gel and a 3851 bp fragment was seen (Figure 1). The pET-28a recombinant vector was constructed as described above; it is about 9200 bp. After transformation of the pET-28a recombinant vector including the desired insert into E. coli, a number of the single colons were taken from the selective medium (LB-kanamycin). Afterwards, the plasmid was extracted. The transformation was confirmed with colony PCR, digestion of extracted plasmid (Figure 2), and sequencing. After the digestion, the PCR product (3851 bp) and the PET-28a vector (5369 bp) were separated. Production of PHB was confirmed by Sudan Black B staining under a light microscope (Figure 3).

Polymerase Chain Reaction Result on 1% Agarose Gel

The right lane is 1 kb DNA size marker (Fermentas, CA) and the left lane is the PCR product (3851 bp).

Figure 1.

Polymerase Chain Reaction Result on 1% Agarose Gel

Digestion of the Extracted Plasmid

1) First digest of the recombinant plasmid; 2) double-digest of the recombinant plasmid; M) 1 kb DNA size marker.

Figure 2.

Digestion of the Extracted Plasmid

Sudan Black Staining of Poly 3-Hydroxybutyrate Granules

Figure 3.

Sudan Black Staining of Poly 3-Hydroxybutyrate Granules

5. Discussion

PHAs are biodegradable polymers which could be a good substitute for current petrochemical plastics. PHA-producing genes exist in various bacteria. Although these genes are dispersed on chromosome in some organisms, they are in tandem in other bacteria such as R. eutropha H16. Although the capacity of R. eutropha to produce and accumulate polymers is well-known, the use of these kinds of bacteria has some limitations. Hence, many efforts have been accomplished to create recombinant bacteria and use economic carbon sources. In a report by Galehdari et al. (11) they separately amplified the phbB, phbA and phbC genes from the extracted Azotobacter genome and cloned the fragments in pCR^®2.1-TOPO^® cloning vector with subsequent transformation of E. coli DH5α. In their study, three types of recombinant E. coli were created and none of them could produce PHB. In our study, the whole operon of PHB was extracted and an expression vector was constructed; then, the production of PHB was confirmed in the recombinant bacteria. Many other reports used phb genes from R. eutropha and A. latus for production of PHB in E. coli (12, 13). Various metabolic and fermentation methods have been used in some bacterial strains for PHB production. The use of a recombinant system harboring the PHB synthesis genes can produce PHB in higher concentrations compare to natural PHA-producing bacteria (2). The high-yield production of PHB in natural PHA-producing bacteria can be reduced by high activity of intracellular depolymerase. To overcome this bottleneck, metabolically-engineered E. coli strains (without dehydrogenase) harboring heterologous PHA synthesis have been established (14).

Intensive efforts are being made to reduce the cost of production by means of bioprocess designing and metabolic engineering of the production strains (2). In this study, we successfully cloned and expressed the recombinant pET-28a containing the PHB-biosynthesis genes. PHB granules were observed in E. coli by Sudan Black B staining under the light microscope. In Sudan Black B staining, lipid inclusion granules were stained blue-black or blue-grey, whilst the bacterial cytoplasm was stained light pink. Therefore, PHB was produced from the recombinant E. coli BL21.
