Abstract
Introduction:
Morgagni hernia is a type of congenital diaphragmatic hernia defined as a defect in the fusion of musculinization of the anterior pleuroperitoneal membrane, occurring in 1 per 3000 live births worldwide.Case Presentation:
The patient was a one-year-old boy residing in the city of Kermanshah, Iran, visiting the hospital following cold signs one month before. After lung auscultation by the physician and performing chest radiography, the patient underwent further examination due to reduced lung sounds on the left side. In the chest radiography, intestine segments and stomach were shown to have entered the left side of the thoracic cavity, and the heart and mediastinum were shifted to the right. In the small intestine transit, part of the stomach fundus was observed in the lower left side of the thoracic cavity, indicative of sliding hiatal hernia.Conclusions:
Intraoperative findings suggested atypical Morgagni hernia. Therefore, it is recommended that surgeons take into account rare types of hernia in their diagnoses, and perform more careful pre-operative radiography to be fully prepared.Keywords
1. Introduction
Congenital diaphragmatic hernia is a congenital diaphragmatic defect occurring in 1 per 3000 live births worldwide (1). It is fatal in 35% of infants, and the rest suffer chronic diseases such as reduced respiratory function and asthma (2). Moreover, the defect in the diaphragm allows abdominal viscera to protrude into the chest, causing mass effect and thereby preventing the natural development of the lung (3). Hernia through the subcostosternal part of the diaphragm that contains the omentum and intestine was first reported by an Italian anatomist in 1761 (4). In congenital diaphragmatic hernia, the defect may occur in the right, left or, in rare cases, both sides. This occurs contrary to the usual state in atypical cases, and the defect is manifested on the right and with the presence of the liver in the thoracic cavity (5). Different types of congenital diaphragmatic hernia include hiatus, Morgagni, and Bochdalek hernia. Bochdalek hernia is the most prevalent type of congenital hernia in which abdominal viscera enter the thoracic cavity due to a defect in the diaphragm, reducing the space for the development of the lung. As a result of pulmonary hypoplasia, many infants suffer from severe respiratory dysfunction immediately after birth, resuscitation, and operation. Esophageal hiatal hernias often demonstrate the signs of gastroesophageal reflux disease (GERD). The Morgagni hernia is rare, often diagnosed accidentally in regular ultrasound of asymptomatic patients (6). Any disorder in the fusion or musculinization of the anterior pleuroperitoneal membrane leads to an anatomic defect of the costosternal trigone, known as the Morgagni’s foramen. As the peritoneum is intact, Morgagni hernia has a true sac and, in most cases, the hernia sac only contains the omentum. However, the presence of the colon and, in rare cases, the small intestine and stomach has also been reported (7). Morgagni hernia is rare in the general population, and therefore few studies have been conducted on it (8). In children, Morgagni hernia may be associated with non-specific signs and confusing paraclinical presentation. Therefore, timely diagnostic and therapeutic measures can save the patient from death and severe complications (9).
2. Case Presentation
The patient was a one-year-old boy residing in the city of Kermanshah, Iran, visiting the hospital following cold signs one month before. After lung auscultation by the physician and performing chest radiography, the patient was referred to a pediatrician due to reduced lung sounds on the left side. The patient did not have dyspnea or a history of taking any specific medications. He had a history of physiological jaundice, and a hemangioma was found on the right eyelid in the examination of the face. After examining the patient’s state, he was hospitalized in Dr. Mohammad Kermanshahi Hospital. Cardiac consultation and echocardiography were performed, suggesting mild heart murmur, moderate ASD, VSD, mild shunt, and PS. In the chest radiography, the segments of the intestine and stomach were shown to have entered the left side of the thoracic cavity, and the heart and mediastinum were shifted to the right. Congenital diaphragmatic hernia in the left and the possibility of adenomatoid malformation of the left lung were reported for the patient. Furthermore, upper GI series showed part of the colon (spleen flexure) had entered the thorax, suggesting CDH diagnosis. The right lung was satisfactory. In the small intestine transit, part of the stomach fundus was observed in the lower half of the left side of thoracic cavity, suggesting sliding hiatal hernia. In the lower half of the left hemithorax, shadows were seen which were reported to be related to the sliding hiatal hernia (Figure 1).
Radiography before surgery. A, small intestine transit before the operation; B, radiography of the patient before the operation
3. Discussion
Morgagni hernia is a congenital defect of the diaphragm presenting with different signs, and its timely diagnosis and treatment are essential for the infant’s survival. In the present study, the initial signs were those of a common cold. However, careful examination revealed that the segments of the intestine and stomach had entered the left side of the thoracic cavity, and the heart and mediastinum were shifted to the right. Moreover, part of the colon had entered the thorax, and part of the stomach fundus was seen in the lower half of the left side of the thoracic cavity in the small intestine transit. Other studies have reported the entrance of colon to the thorax, and the small intestine transit. Congenital heart diseases are observed with Morgagni hernia in 58% of cases (10). However, according to some articles, this hernia may be asymptomatic and only present itself as a lesion on the stomach (9). Various surgical methods are available for repairing the hernial sac and returning the viscera to the abdomen. In the present study, open surgery through the abdomen like that used by Morgagni was selected (11). However, open surgery through the thorax, laparoscopy, and patch repair have also been reported for these patients (12-14). The patient underwent laparotomic surgery with left subcostal incision. After opening the site of the operation, findings suggested atypical Morgagni hernia. Contrary to the usual case, the defect continued to lateral and posterior parts as well. The colon, part of the stomach, and liver which were inside the left hemithorax were returned to the abdomen, the hernial defect was repaired (Figure 2), and the abdominal layers were repaired respectively.
During the surgery
3.1. Conclusions
Intraoperative findings suggested atypical Morgagni hernia. Therefore, it is recommended that physicians take into account rare types of hernia in their diagnoses, and perform more careful pre-operative radiography to be fully prepared. Clinical signs and findings during the patient follow-up suggested an improvement in his status and the repair of the defect caused by hernia (Figure 3).
Follow-up radiography
References
-
1.
Su H, Mu L, Liu C. Protective effect of baicalin on fetal lung development in a rabbit model of congenital diaphragmatic hernia. Exp Ther Med. 2018;15(1):61-6. [PubMed ID: 29387182]. [PubMed Central ID: PMC5769275]. https://doi.org/10.3892/etm.2017.5409.
-
2.
Tsao K, Lally KP. The Congenital Diaphragmatic Hernia Study Group: A voluntary international registry. Semin Pediatr Surg. 2008;17(2):90-7. [PubMed ID: 18395658]. https://doi.org/10.1053/j.sempedsurg.2008.02.004.
-
3.
Xia B, Hong C, Tang J, Liu C, Yu G. Congenital diaphragmatic hernia in association with congenital short esophagus: A case report. Medicine (Baltimore). 2017;96(51). e8996. [PubMed ID: 29390430]. [PubMed Central ID: PMC5758132]. https://doi.org/10.1097/MD.0000000000008996.
-
4.
Moshkgoo M, Shams Akhtary A. Case report of Morgagni hernia. Iran Univ Med Sci J. 2010;16(62):173-7.
-
5.
Klein J, Sirota M. Congenital diaphragmatic hernia. N Engl J Med. 2017;377(17). e25. [PubMed ID: 29069554]. https://doi.org/10.1056/NEJMicm1701321.
-
6.
Sakoda A, Matsufuji H. [Current management of congenital diaphragmatic hernia]. Kyobu Geka. 2015;68(8):676-83. Japanese. [PubMed ID: 26197915].
-
7.
Peyvandi H, Mousavian SA. Report of one case of Morgani hernia in triosomy 21. Iran Surg J. 2009;17(1):1-5.
-
8.
Thomas TV. Subcostosternal diaphragmatic hernia. J Thorac Cardiovasc Surg. 1972;63(2):279-83. [PubMed ID: 5009742].
-
9.
Javanmardi M, Naghavi M. Report a case of Morgagni hernia with intestinal Volvulus. Feyz J. 2006;10(3):62-5.
-
10.
Fagelman D, Caridi JG. CT diagnosis of hernia of Morgagni. Gastrointest Radiol. 1984;9(2):153-5. [PubMed ID: 6745593].
-
11.
Minneci PC, Deans KJ, Kim P, Mathisen DJ. Foramen of Morgagni hernia: Changes in diagnosis and treatment. Ann Thorac Surg. 2004;77(6):1956-9. [PubMed ID: 15172245]. https://doi.org/10.1016/j.athoracsur.2003.12.028.
-
12.
Brunicardi FC, Andersen DK, Billiar R, Dunn DL, Hunter JG, Pollock RE. Schwartz's principles of surgery. 2010. 8th ed. New York, NY: McGraw-Hill; 2005.
-
13.
Angrisani L, Lorenzo M, Santoro T, Sodano A, Tesauro B. Hernia of foramen of Morgagni in adult: Case report of laparoscopic repair. JSLS. 2000;4(2):177-81. [PubMed ID: 10917128]. [PubMed Central ID: PMC3015372].
-
14.
Behrman RE, Kliegman RM, Jenson HB. Nelson's text book of pediatrics. 17th ed. Philadelphia: W.B. Sounders Company; 2004.
