Abstract
Background:
In clinical area, assessment of body fluid and determination of the intravascular volume after major surgeries such as heart surgery is a significant challenge. The initial purpose of intravascular volume assessment in patients with hemodynamic instability is to determine whether they would benefit from fluid administration or not.Objectives:
This study aims to compare pulse pressure variation (PPV) compared to thoracic fluid content in checking out and optimizing fluid volume in mechanically ventilated patients admitted to intensive care unit after cardiac surgery.Methods:
In the present study a prospective descriptive-analytic design was used. Thirty mechanically ventilated patients admitted to intensive care units of Rajaie heart center, Tehran, Iran, were recruited in the current study after cardiac surgery based on inclusion criteria. Data collection tools included demographic and clinical data sheets. Hemodynamic parameters such as CVP and pulse pressure were recorded by bedside monitoring. Thoracic fluid content (TFC) was measured by non-invasive continuous cardiac output monitoring (NICCOMO) system. Data were analyzed in SPSS version 15, using statistical tests.Results:
The mean values of CVP, before and five minutes after fluid administration were significantly different (10.10 ± 6.01 mmHg and 12.37 ± 6.34 mmHg, respectively, P = 0.015). The mean changes in arterial pulse pressure, before and five minutes after fluid administration were significantly different (16.94 ± 8.32 mmHg and 12.77 ± 4.02 mmHg, respectively, P = 0.005). PPV greater than 13% had sensitivity, specificity and positive predictive value of 40%, 71% and 75% respectively while CVP greater than 5 mmHg had sensitivity, specificity and positive predictive of 13%, 85% and 66% respectively compared with cardiac index as the gold standard for fluid responsiveness. These findings suggest a higher diagnostic power of PPV compared to CVP to assess fluid volume.Conclusions:
It seems that in the mechanically ventilated patients after heart surgery, PPV dynamic index is preferred to CVP static index to evaluate and maintain fluid volume.Keywords
Pulse Pressure Variation Central Venous Pressure Thoracic Fluid Content Mechanical Ventilation Intensive Care Unit Cardiac Surgery
1. Background
The measurement of intravascular volume status to optimize the cardiac preload for the purpose of improving cardiac output and tissue perfusion is very important in caring critically ill patients (1, 2). But before the administration of fluids, assessment of patients’ response to increased fluid volume is necessary to prevent an unnecessary and harmful fluid imbalance. Volume administration can be done when we expect an increase in left ventricular stroke volume (3). In healthy individuals, increased preload by fluid administration, was associated with a significant increase in ventricular stroke volume. In contrast only 50% of hemodynamically unstable patients had an increase in ventricular stroke volume. Cardiac filling pressures, including the central venous pressure (CVP) and pulmonary artery occlusion pressure and other routine indexes such as urine output and arterial blood pressure have been traditionally used to guide fluid management. However, several studies have demonstrated that these parameters are unable to predict fluid responsiveness (4).
CVP is a good indicator of RV preload (4). Furthermore, because RV stroke volume determines LV filling, CVP is considered as an indirect measurement of LV preload. However, due to changes in venous tone, intrathoracic pressures and LV/RV compliance that occur in critically ill patients, there is a poor relationship between CVP and fluid responsiveness (4).
A dynamic index like arterial pulse pressure variation (PPV) is more accurate than static indices in predicting fluid responsiveness (5). PPV which shows changes in venous return and stroke volume during mechanical ventilation, predicts left ventricular preload reserve so that it can be used for fluid management (6).
The Purpose of the current study is to compare the clinical utility of CVP and PPV to predict fluid responsiveness in patients who have undergone mechanical ventilation. The authors’ hypothesis was PPV could be more effective than CVP to predict fluid responsiveness via evaluation of TFC as an accurate indicator of fluid responsiveness.
2. Methods
2.1. Patients
This study was conducted in cardiac surgery intensive care units in Rajaie cardiovascular medical and research center between March 2015 to August 2015. The studied population was the patients who underwent open heart surgery CABG, valvular and combined surgery (valvular and CABG) following mechanical ventilation. 33 patients who met inclusion criteria were enrolled but 3 patients were excluded during study because of hemodynamic instability. Inclusion criteria were: Patients under anesthesia and mechanical ventilation with fixed settings and no change in controlled mode, tidal volume of greater than 8 mL per kilogram of body weight, sinus rhythm and age between 20 to 70 years.
This study was approved by our local ethical committee according to the Helsinki declaration of the world medical association (2000).
2.2. Mechanical Ventilation
All patients were monitored using an arterial catheter. Transducers which were placed at the level of the fourth intercostal space in the mid-axillary were zeroed to atmospheric pressure. Due to the fact that any spontaneous breathing reduces the inside pressure of chest and results in false results in measured hemodynamic parameters, patients were sedated with propofol and opioids such as morphine.
2.3. Hemodynamic Parameters
CVP was assessed at end-expiration continuously. Systolic and diastolic blood pressures were evaluated from arterial pressure monitoring and pulse pressure was measured from systolic and diastolic blood pressure differences. Pulse pressure was determined using at least three measurements average performed at end-expiration.
Cardiac parameters were assessed using NICCOMO (Medizinische Messtechnik GmbH, Germany) with ACM technology by non-invasive methods continuously. The device is based on the method of Impedance Cardiography (ICG). ICG waves show changes in volume and velocity of blood in the aorta by creating variations in the thoracic impedance and are displayed as algorithms to provide key hemodynamic parameters non-invasively and continuously (NICCOMO, medis, https://medis.company/cms/?page=niccomo).
2.4. Fluid Administration
For volume expansion, we used crystalloid solution (ringer or normal saline) and colloid solution (Valoven 6%, gelatin, albumin 5%) in ratio of 2/1 via central vein catheter over 20 minutes by CVP and PPV monitoring. Hemodynamic parameters were measured immediately before and 5 minutes after the volume expansion. There were no changes in vasoactive and sedative infusions or to ventilator settings during the study period. Endotracheal suctioning and fluid or blood products administration were avoided during patients’ monitoring.
2.5. Statistics
Data were expressed as mean values ± standard deviation for interval and count (%) for categorical variables. All variables were tested for normal distribution with Kolmogorov-Smirnov test. To study the changes of quantitative data before and after fluid administration, paired t-test was used. The ROC curve was used to determine the area under the curve (AUC), and the optimum cardiac index cut-off level. Statistical analyses were performed with SPSS (ver 15; SPSS Inc. Chicago, Illinois). P values < 0.05 were considered significant.
3. Results
3.1. General Characteristics
Overall, 30 patients (20 men and 10 women, age: 61.4 ± 6.97) were recruited. The characteristics of the patients are demonstrated in Table 1.
Patients Characteristics
| Variables | No (%) or M ± SD |
|---|---|
| Sex | |
| Male | 20 (66.7) |
| Female | 10 (33.3) |
| Age | 61.4 ± 6.9 |
| Weight | 71.3 ± 10.5 |
| EF | 44.6 ± 6.8 |
| Pump time | 100.11 ± 38.45 |
| Cross clamp time | 62.27 ± 25.02 |
3.2. Assessment of Hemodynamic Parameters
Hemodynamic measurements at baseline and after volume expansion are shown in Table 2. CVP increased significantly (P: 0.01) and PPV decreased significantly (P: 0.005) in response to fluid administration while SVI, CO, CI and SV were not changed significantly after fluid expansion (P < 0.05).
Comparison of Hemodynamic Parameters Before and After Volume Expansion
| Variables | Baseline | Volume Expansion | P Value |
|---|---|---|---|
| CVP | 10.10 ± 6.01 | 12.37 ± 6.34 | 0.01 |
| PPV | 16.94 ± 8.32 | 12.77 ± 4.02 | 0.005 |
| SVI | 33.04 ± 8.92 | 33.45 ± 9.29 | 0.74 |
| CI | 2.90 ± 0.63 | 3.09 ± 0.55 | 0.09 |
| CO | 4.89 ± 1.12 | 4.74 ± 1.19 | 0.40 |
| SV | 60.18 ± 18.15 | 59.27 ± 17.51 | 0.73 |
| TFC | 46.84 ± 8.25 | 46.90 ± 7.89 | 0.89 |
3.3. Diagnostic accuracy of CVP and PPV
There was no agreement between PPV and CVP (Kappa: -0.021, P: 0.90).
Diagnostic accuracy indices for PPV and CVP compared to gold standard are seen in Table 3. Our results show that PPV is more accurate than CVP for fluid responsiveness after cardiac surgery. Although PPV and CVP are the same regarding accuracy indices, PPV seems to be a more useful indicator of fluid responsiveness than PPV based on sensitivity and positive predictive value.
Diagnostic Accuracy of CVP and PPV Compared with CI and TFC
| Variables | CI ≥ 2.8 | TFC ≥ 50 | ||
|---|---|---|---|---|
| % | 95%CI | % | 95%CI | |
| CVP ≥ 5 | ||||
| Sensitivity | 13.33 | 1.66 - 40.46 | 12.50 | 1.55 - 38.35 |
| Specificity | 85.71 | 42.13 - 99.64 | 83.33 | 35.88 - 99.58 |
| Positive predictive value | 66.67 | 17.75 - 94.88 | 66.67 | 18.00 - 94.80 |
| Negative predictive value | 31.58 | 24.32 - 39.86 | 26.32 | 19.27 - 34.83 |
| PPV ≥ 1.3 | ||||
| Sensitivity | 40.00 | 16.34 - 67.71 | 43.75 | 19.75 - 70.12 |
| Specificity | 71.43 | 29.04 - 96.33 | 83.33 | 35.88 - 99.58 |
| Positive predictive value | 75.00 | 44.36 - 91.86 | 87.50 | 51.81 - 97.85 |
| Negative predictive value | 35.71 | 22.93 - 50.92 | 35.71 | 24.07 - 49.33 |
4. Discussion
An adequate volume expansion would decrease the risk of organ injury due to hypo-perfusion and hypovolemia, therefore it would avoid the risk of volume overload in patients who underwent cardiac surgery. Recently, goal-directed fluid management protocols were used to decrease the morbidity related to cardiovascular surgery. Several studies demonstrated that dynamic measures of preload responsiveness such as PPV are preferred to static preload parameters like CVP in fluid management (7, 8). But some other studies note to CVP as a simple and readily available measurement that can provide a useful guide to the management of hemodynamically unstable patients (2).
Our study showed that PPV during mechanical ventilation can be used to accurately predict fluid responsiveness after cardiac surgery. In contrast, CVP was a poor predictor of fluid responsiveness. Our findings show that although CVP had reached a considerable level after fluid administration, it was not in line with increased cardiac index and other cardiac functional indices. It can be concluded that increase in CVP cannot be effective in improving the prognosis of patients. Yazigi A et al. concluded that PPV, but not baseline CVP, can be used to guide fluid therapy especially in old patients with limited physiologic reserves (6). Nevertheless, dynamic preload monitoring like PPV has some limitations such as arrhythmia and patient condition without mechanical ventilation support (9).
We showed that PPV is a better predictor of fluid responsiveness than CVP because it has a higher sensitivity and positive predictive value than CVP. In our results, PPV greater than 13% had sensitivity, specificity and positive predictive value of 40% , 71% and 75% respectively while CVP greater than 5 mmHg had sensitivity, specificity and positive predictive of 13%, 85% and 66% respectively compared with cardiac index as the gold standard for fluid responsiveness.
Michard et al. reported a PPV of 13% to have the highest sensitivity and specificity to predict an increase in CO in response to volume expansion (10). Karmar A et al. found a PPV value > 11% predicted an increase in CO with 100% sensitivity and 93% specificity (1). The reason for higher amount of sensitivity and specificity of Karmar A et al. study seems to be our small sample size.
Thoracic fluid content (TFC) is an indicator of total fluid volume, both intracellular and extracellular. Because it is measured noninvasively using impedance cardiography (ICG), has an exact reliable test and it is one of the cut point monitoring for prevention of fluid overload (11). In the current study, we found that TFC is an efficient indicator to predict fluid overload. So, the combination of noninvasive measurements of both TFC and CI obtained from the ICG monitor can help manage fluid expansion in patients after surgery.
4.1. Conclusion
In summary, in contrast to CVP, PPV is a reliable predictor of increased CI in response to fluid expansion during controlled mechanical ventilation in patients after cardiac surgery and it is a good index to manage fluid therapy in these patients and reduce postoperative morbidity and mortality caused by increased volume of fluid.
There are several hemodynamic indices used for fluid management such as stoke volume index, pulmonary capillary wedge pressure and mixed venous or central venous oxygen saturation since they are useful but they have some limitations in usage.
