Study instruments were a demographic form and the face, legs, activity, cry, and consolability (FLACC) scale (
17). The demographic questionnaire included items on gender, weight, crying length, time interval between the last sleep and vaccination, time interval between the last feeding and vaccination, and previous experience of painful procedures. The FLACC scale was developed and validated in 1997 by Merkel et al. in the University of Michigan (
17). It assesses facial expression, leg posture, activities, crying, and consolability in response to the pain. The score of each domain can range from zero (“no response”) to 2 (“maximum response”), resulting in a total score of 0 - 10. Scores 0 - 3, 4-7, and 7 - 10 represent mild, moderate, and severe pain, respectively. Two previous studies reported that the inter-rater correlation coefficient and the Kappa agreement coefficient of the scale were 0.94 and 0.82, respectively, confirming its acceptable reliability (
18,
19). A study in Iran also found a significant correlation between the scores of the FLACC scale and the Faces Pain Scale, with a correlation coefficient of 0.707 (
16). For reliability assessment in the present study, two raters simultaneously applied the FLACC scale to fifteen infants. The inter-rater correlation coefficient was 0.73. For pain assessment using the FLACC, participants were filmed from the beginning of the injection to three minutes afterward. Then assistant researchers who were blind to the study aims used the FLACC scale to assess the movies and rate pain intensity. The length of crying was also measured using a digital stopwatch (HS34, Q&Q), the reliability of which had been confirmed using a similar stopwatch.
