Abstract
Introduction:
Chronic recurrent multifocal osteomyelitis (CRMO) is a rare migratory skeletal disorder with non-infectious inflammatory etiology which usually causes bone pain in children and adolescents. Intermittent periods of exacerbation and remission are usually noted during the course of the disease. It is a multifocal bone disease usually involving the metaphyses of long bones. The clinical and Paraclinical findings are non-specific, and indeed CRMO is a diagnosis of exclusion based on multiple criteria.Case Presentation:
We present a 6-year-old boy with multiple periods of fever, systemic inflammation and bone pain since he was 2 years old, hospitalized multiple times, received antibiotics and finally diagnosed as a CRMO case.Conclusions:
CRMO should be diagnosed according to a variety of clinical and paraclinical findings. In children and adolescents with multiple bone lesions and lytic lesion, one of the differential diagnoses that should be considered is CRMO.Keywords
1. Introduction
Chronic recurrent multifocal osteomyelitis (CRMO) is an uncommon form of osteitis in children with probably autoimmune origin. It is a rare immigrant inflammatory bone process with intermittent periods of exacerbations and remissions involving multiple sites. Infectious pathogens from affected areas cannot be isolated (1). It was first described by Giedione et al. (2) in 1972 as “an unusual form of multifocal bone lesions with subacute and chronic symmetrical osteomyelitis.” Bjorksten and Boquuist (3) understood its relationship with pustulosis and they used the term “chronic recurrent multifocal osteomyelitis.”
CRMO is more common in females (4). Lesions typically affect metaphyseal region of long bones but can occur in any bone (such as clavicle) (5-7). Apart from the bone, other organs such as lungs, gastrointestinal tracts and the eyes can also be involved (8). CRMO should be diagnosed with caution. Being aware of the disease helps to preclude the unnecessary use of antibiotic therapy (9). In this report, the case of a 6-year-old with CRMO – which was initially misdiagnosed and treated by multiple courses of different types of antibiotics – is presented.
2. Case Report
In 2012, a 2-year-old boy was admitted to the hospital with chief complaint of fever, axial skeleton pain (more in the lumbar region) and difficult walking. Symptoms had been started 2 months prior to the patient's admission. Laboratory investigations at that time showed erythrocyte sedimentation rate (ESR) of 75 and positive C-reactive protein. Conventional X-ray (CXR) did not show any significant finding in favor of infectious process; however, a lytic lesion was noted in the body of L5/S1 in computed tomography (CT) scan. Radiologist suggested the lesion could be due to tumoral involvement or infectious process such as tuberculosis . Other tests including blood culture, PPD, Wright and Coomb’s-Wright were all negative. Bone marrow aspiration did not show any specific pathology. Antibiotics therapy (ceftriaxone, clindamycin) was started. According to the radiographic findings, the patient was candidate for open biopsy from lumbar lesion. Moreover, only granulomatous inflammation was reported in pathological evaluation without acid fast bacilli in Ziehl-Nelson staining. Bone culture did not show any organism. Polymerase chain reaction (PCR) analysis was also negative for tuberculosis. In whole body bone scan, multiple foci of increased uptake were noted in the left side of the skull, proximal portion of the left humerus, left femoral neck, distal physis of right femur, L4-L5 vertebrae and posterior arc of the left upper rib. Another bone biopsy from the right femoral lesion was performed and histopathological findings were again in favor of chronic granulomatous inflammation.
In 2014, he was readmitted to the hospital for more diagnostic workup (due to repeated history of bone pain and fever). Bone scintigraphy (Figure 1) revealed new bone lesions in the medial portion of the left clavicle, sacrum, left SI joint, L5 and minimal activity in the left side of the occipital bone. CT scan (Figure 2) showed multiple lytic lesions in the iliac and sacral bones with periosteal reaction. A third bone biopsy from the clavicle lesion was performed and again nonspecific histopathological findings were reported which were compatible with granulomatous inflammation. No organism was obtained from tissue culture, and acid fast staining was negative. The pathologist suggested Eosinophilic granuloma (histiocytosis X) due to histopathological findings. Consequently, the antibiotic therapy was discontinued but due to decreased symptoms the patient refused for more follow up. Two years later on early 2016, the patient was admitted one more time with fever, right arm pain and swelling; besides a necrotic ulcer in the nose was also observed (Figures 3A and 3B). According to nasal ulcer, leprosy was also suspected. Although no sign in favor of skin sensation loss was noted, another biopsy from nasal lesion was performed. Histopathological findings were again in favor of granulomatous inflammation. PCR results and skin smears were negative for leprosy. The patient was referred to our department for bone scan. Bone scintigraphy (Figure 4) revealed increased radiotracer uptake in the right facial bones, right 3rd and 6th ribs, T4, T12, L1, proximal part of left ulna and right iliac bone. ESR was 59 and all other workups including viral marker, flocytometry, immunologic workup, and PPD were unremarkable. The bone scan were compared with previous imaging and considering the immigrant and intermittent nature of the disease CRMO was proposed as the first differential diagnosis and histopathological review of previous biopsies were recommended. Pathological consultation with an expert confirmed the CRMO. Following the diagnosis, prednisolone was started and symptoms subsided. He is now being followed for about 1 year and is still using methotrexate but his symptom is under control.
Planar Bone Scan Showing Uptake in the Medial Portion of the Left Clavicle, Sacrum, Left SI Joint, L5 and Minimal Activity in the Left Side of the Occipital Bone
A, Pelvic CT Scan Showing Multiple Lytic Lesions in the Iliac and Sacral Bones with periosteal reaction; B, Pelvic CT Scan Showing Multiple Lytic Lesions in the Iliac and Sacral Bones with Periosteal Reaction
A, Nasal Necrotic Ulcer: Pre-Treatment; B, Nasal Necrotic Ulcer: Post-Treatment
Bone Scan Showing an Increased Radiotracer Uptake in the Right Facial Bones, Right 3rd and 6th Ribs, T4, T12, L1, Proximal Part of Left Ulna and Right Iliac Bone
3. Discussion
CRMO is a rare skeletal disorder, usually presenting with bone pain and shows intermittent periods of exacerbations and remissions (1). It should be considered as a variant of osteomyelitis (2% - 5%) (10) which is thought to have an autoimmune origin. It is more prevalent in females, and usually the mean age of the patients at its onset is about 10 years old (4, 11). Patient’s symptoms usually continue for several years (median duration is about 6 years). Metaphyseal regions of long bones (distal femur, proximal tibia, distal tibia and distal fibula) are more affected. Other sites of the skeleton which could be involved are clavicles, spine, pelvis and ribs. Mandibular involvement is noted in about 1.5% - 3% of the patients with CRMO (5-7, 12-14).
Systemic symptoms such as low grade fever and skin lesions can accompany patient’s symptoms. Other non-musculoskeletal disorders related to CRMO include arthritis, palmoplantar pustulosis, Crohn’s disease, growth hormone deficiency and psoriasis (15). Elevated ESR is the most remarkable laboratory finding, but anemia and leukocytosis are not detected and also tissue and blood cultures are negative (8).
CRMO may be visible as lytic lesions in the radiography in early phases and later hyperostosis and sclerosis are noted; periosteal reactions can also occur. Also, increased radiopharmaceutical uptake in multiple sites is observed on bone scintigraphy (1, 16).
The etiology of CRMO is not well understood. Since the blood and tissue cultures are negative, a noninfectious inflammatory process is the main culprit. Moreover, considering the relationship of CRMO with multiple autoimmune diseases, an autoimmune disorder is also suspected as the cause of the CRMO (17).
In the histopathology of patient with CRMO, the granulomatosis changes may be seen which are noncaseating; Caseous granulomas are mainly seen in TB osteomyelitis. But Assari et al reported a CRMO case that showed caseous granulomas (18).
Some authors have stated that CRMO is the pediatric form of SAPHO syndrome (synovitis, acne, pustulosis, hyperostosis, and osteitis) (19, 20).
Different kinds of treatments including non-steroidal anti-inflammatory drugs, corticosteroids, DMARDs, and bisphosphonate can be used (21). Overall, the patients’ prognosis is good; however, sometimes the disease persists until adulthood and can cause long term side effects.
CRMO is suspected when repeated episodes of bone pain in different locations occur in a child with some nonspecific findings in plain radiography (which could suggest subacute or chronic osteomyelitis) but without exact histopathological results; also no organism is obtained from tissue or blood culture.
In this case, the patient had low back pain and fever with lytic lesion in the L5/S1; therefore, tumoral involvement and infectious process such as tuberculosis or brucellosis was considered in differential diagnosis. However, tissue biopsy did not prove it. According to initial work up, Langerhans cell histocytosis was also suspected, but it was not confirmed on follow up. The interesting point in this case was the patient's nasal ulcer, which – given the fact that he came from an endemic leprosy area – made other causes such as leprosy a plausible scenario. Nasal ulcer biopsy and palatin bone biopsy showed only granulomatous changes. PCR results and skin smears were negative for leprosy. So due to the histopathological findings and patient symptom, leprosy was ruled out. Eventually, based on the patient's history of episodic bone pain involving different sites and bone scan suggestion CRMO was diagnosed and treated accordingly. He is now being followed for more than one year and still is using methotrexate, and his symptoms are under control.
3.1. Conclusion
CRMO should be diagnosed according to a variety of clinical and para clinical findings. In children and adolescents with multiple bone lesions, one of the differential diagnoses that should be considered is CRMO to prevent multiple bone biopsies and mistreatment.
