Plant material
Lichen samples of CA, CC and CO were collected from Giresun province of Turkey in 2010. The samples were identified by Associate Prof. Dr. Ali ASLAN, using various flora books and papers (26-28). Vouchers were stored in the herbarium of Kazım Karabekir Education Faculty, Ataturk University (the herbarium number of CA: ATA-KKEF-1865, CC: ATA-KKEF-1866 and CO: ATA-KKEF-1876).
| Test Items | Concentration (µg/plate) | Number of revertants
|
|---|
E. coli WP2uvrA
| S. typhimurium TA1535
| S. typhimurium TA1537
|
|---|
| Mean S.E. | Inhib. % | Mean S.E. | Inhib. % | Mean S.E. | Inhib. % |
|---|
| Mutagen agent (positive control) | MNNG (1), NaN3(1) 9-AA(40) | 285.500 07.15 | | 548.00 12.26ö | | 311.00 07.16ö | |
| DMSO** (µL/plate) | 100 | 28.00 01.23 | | 12.50 01.00 | | 11.00 01.20 | |
| CA | 2 | 258.50 04.50 | - | 361.50 08.45 | 34.03 | 292.00 03.40 | - |
| 4 | 259.50 03.78 | - | 376.50 07.29 | 31.38 | 229.00 05.27 | 26.36 |
| 6 | 241.00 04.08 | - | 387.50 10.13 | 29.28 | 220.00 04.50 | 29.26 |
| 8 | 219.50 05.60 | - | 408.50 08.10 | 25.45 | 214.00 05.63 | 31.18 |
| 10 | 261.00 02.23 | - | 431.00 06.82 | 21.35 | 184.00 04.30 | 40.83 |
| Mutagen agent (positive control) | | 561.00 01.47 | | 548.00 01.36 | | 347.00 00.85 | |
| DMSO** (µL/plate) | 100 | 23.00 02.04 | | 12.50 01.14 | | 11.00 01.26 | |
| CC | 2 | 350.00 02.70 | 37.61 | 371.00 08.40 | 32.29 | 251.00 05.48 | 27.66 |
| 4 | 362.50 05.00 | 35.38 | 397.50 05.45 | 27.46 | 243.50 04.27 | 29.82 |
| 6 | 396.50 04.10 | 29.32 | 331.00 10.00 | 39.59 | 203.50 05.16 | 41.35 |
| 8 | 334.00 03.06 | 40.46 | 408.50 04.22 | 25.45 | 198.00 03.34 | 42.93 |
| 10 | 372.00 03.88 | 33.68 | 441.00 06.45 | - | 203.50 05.30 | 41.35 |
| Mutagen agent (positive control) | | 458.00 04.00 | | 487.00 01.75 | | 347.00 00.74 | |
| DMSO** (µL/plate) | 100 | 33.00 03.17 | | 12.50 01.06 | | 11.00 01.23 | |
| CO | 2 | 355.50 02.50 | 22.37 | 319.00 07.18 | 34.49 | 212.00 04.40 | 38.91 |
| 4 | 368.00 02.18 | - | 302.50 10.00 | 37.88 | 255.00 02.51 | 26.51 |
| 6 | 389.50 05.42 | - | 341.50 08.20 | 29.87 | 253.00 02.57 | 27.08 |
| 8 | 386.50 06.00 | - | 389.00 04.50 | 20.12 | 188.00 01.90 | 45.82 |
| 10 | 376.50 02.60 | - | 353.50 06.27 | 27.41 | 163.50 04.35 | 52.88 |
P <0,05,
MNNG, NaN3 and 9-AA were used as positive controls for E. coli WP2uvrA, S. typhimurium TA1535 and TA1537 strains, respectively. 10% DMSO (dimethylsulfoxide) was used as negative control. CA: Cetrariaaculeata, CC:Cladonia chlorophae and CO: Cetralia olivetorum. S.E:Standard error.
| Concentrations | Metaphase | Range of SCEs | SCEs/Cell | SCE/Cell ± S.E |
|---|
| Test Items | | | | | |
| Control | | 80 | 2-8 | 421 | 6.91 ± 0.82a |
| AFB | 5 µM | 80 | 6-14 | 476 | 9.60 ± 0.21e |
| CA | 10 µg/mL | 80 | 3-9 | 406 | 6.96 ± 0.13a |
| AFB + CA | 5 µM + 5 µg/mL | 80 | 5-9 | 508 | 8.40 ± 0.10cd |
| AFB +CA | 5 µM + 10 µg/mL | 80 | 3-10 | 471 | 7.93 ± 0.32bc |
| AFB + CA | 5 µM + 20 µg/mL | 80 | 4-10 | 446 | 7.43 ± 0.17b |
| Control | | 80 | 4-7 | 382 | 6.36 ± 0.78a |
| AFB | 5 µM | 80 | 3-13 | 546 | 9.10 ± 0.14e |
| CC | 10 µg/mL | 80 | 4-9 | 412 | 6.86 ± 0.12ab |
| AFB + CC | 5 µM + 5 µg/mL | 80 | 3-11 | 491 | 8.18 ± 0.21d |
| AFB + CC | 5 µM + 10 µg/mL | 80 | 4-10 | 460 | 7.63 ± 0.19c |
| AFB + CC | 5 µM + 20 µg/mL | 80 | 5-10 | 448 | 7.46 ± 0.22bc |
| Control | | 80 | 2-7 | 332 | 5.53 ± 0.67a |
| AFB | 5 µM | 80 | 4-12 | 536 | 8.93 ± 0.41e |
| CO | 10 µg/mL | 80 | 3-9 | 346 | 6.10 ± 0.09a |
| AFB + CO | 5 µM + 5 µg/mL | 80 | 4-10 | 440 | 7.41 ± 0.33cd |
| AFB + CO | 5 µM + 10 µg/mL | 80 | 3-11 | 400 | 6.66 ± 0.27b |
| AFB + CO | 5 µM + 20 µg/mL | 80 | 4-9 | 394 | 6.63 ± 0.16b |
| Test Items | SOD (U/mL) | GPx (U/mL) | GSH (µmol/L) | MDA (nmol/mL) |
|---|
| Control | 1.53 ± 0.22a | 1.18 ± 0.07a | 3.36 ± 0.41a | 1.30 ± 0.17a |
| AFB (5 µM) | 0.97 ± 0.21d | 0.46 ± 0.12d | 1.34 ± 0.12d | 4.69 ± 0.10d |
| CA (10 µg/mL) | 1.62 ± 0.18a | 1.42 ± 0.08a | 3.12 ± 0.13a | 2.66 ± 0.20b |
| AFB (5 µM) + CA (5 µg/mL) | 1.24 ± 0.08bc | 0.98 ± 0.11b | 2.67 ± 0.22bc | 5.44 ± 0. 12d |
| AFB (5 µM) + CA(10 µg/mL) | 1.41 ± 0.16ab | 1.08 ± 0.10ab | 2.98 ± 0.16ab | 3.73 ± 0.21c |
| AFB (5 µM) + CA (20 µg/mL) | 1.49 ± 0.21a | 1.57 ± 0.07a | 3.22 ± 0.18a | 3.02 ± 0.27bc |
| Control | 1.81 ± 0.12a | 0.89 ± 0.12a | 3.92 ± 0.20a | 3.42 ± 0.08a |
| AFB (5 µM) | 0.99 ± 0.43d | 0.51 ± 0.17d | 1.37 ± 0.12d | 4.81 ± 0.13d |
| CC (10 µg/mL) | 1.86 ± 0.22a | 1.44 ± 0.15a | 3.42 ± 0.14a | 3.73 ± 0.10b |
| AFB (5 µM) + CC (5 µg/mL) | 1.74 ± 0.17a | 0.77 ± 0.1b | 2.26 ± 0.19c | 5.53 ± 0.09d |
| AFB (5 µM) + CC (10 µg/mL) | 1.72 ± 0.10a | 0.78 ± 0.21b | 3.84 ± 0.21a | 3.97 ± 0.24bc |
| AFB (5 µM) + CC (20 µg/mL) | 1.71 ± 0.35a | 0.96 ± 0.07a | 3.78 ± 0.17a | 3.51 ± 0.32a |
| Control | 1.65 ± 0.21a | 1.38 ± 0.08a | 3.15 ± 0.20a | 2.41 ± 0.07a |
| AFB (5 µM) | 0.96 ± 0.20d | 0.44 ± 0.18d | 1.35 ± 0.07d | 4.72 ± 0.08d |
| CO (10 µg/mL) | 1.63 ± 0.18a | 1.42 ± 0.25a | 3.18 ± 0.11a | 2.98 ± 0.22b |
| AFB (5 µM) + CO (5 µg/mL) | 1.67 ± 0.09a | 0.80 ± 0.09c | 2.64 ± 0.23b | 2.34 ± 0.21a |
| AFB (5 µM) + CO (10 µg/mL) | 1.69 ± 0.36a | 0.96 ± 0.06b | 2.91 ± 0.07ab | 2.24 ± 0.19a |
| AFB (5 µM) + CO (20 µg/mL) | 1.68 ± 0.13a | 1.18 ± 0.11ab | 3.05 ± 0.15a | 4.60 ± 0.12d |
Preparation of methanol extracts
Air-dried and powdered lichens (20 g) were extracted with 200 mL of methanol using the Soxhlet extractor (Isopad, Heidelberg, Germany) for 48 h at a temperature not exceeding the boiling point of the solvent (
29). The extract was filtered using Whatman fitler paper (no.1) and then concentrated in vacuum at 40 °C using a rotary evaporator (Buchi Labortechnic AG, Flawil, Switzerland) yielding a waxy material.
Cytogenetic analysis of sister chromatid exchange (SCE)
For the cytogenetic analysis of SCE peripheral blood lymphocytes were taken from four nonsmoking healthy donors between the ages of 22 and 25. Lymphocyte cultures were set up by adding 0.5 mL of heparinized whole blood to RPMI-1640 chromosome medium supplemented with 15% heat-inactivated fetal calf serum, 100 IU/mL streptomycin, 100 IU/mL penicillin and 2% L-glutamine. Lymphocytes were stimulated to divide by 2% phytohemagglutinin. Aflatoxin B1 (AFB; 5 µM) and methanol extract of each lichen species (CA, CC and CO) at concentrations of 5, 10 and 20 µg/mL were added to the cultures just before incubation.
For sister chromatid exchange (SCE) demonstration, the cultures were incubated at 37 °C for 72 h and 5-bromo 2-deoxyuridine at 8 µg/mL was added at the initiation of cultures. All cultures were maintained in darkness. Afterward, 3 µg/mL of colcemide was added 90 min before harvesting to arrest the cells at metaphase. The cultures were centrifuged at 1200 rpm for 10 min. The supernatants were used for enzyme analysis. Cells were harvested and treated for 25 min at 37 °C with hypotonic solution (0.075 M KCl) and centrifuged for 10 min at 1200 rpm then fixed in a 1:3 mixture of acetic acid/methanol (vol/vol). The treatment with fixative was repeated three times. Then, the cells were spread on glass slides and air-dried in dark for 1 week. The staining of air dried slides was performed following the modified fluorescence plus 5% Giemsa method for SCE (
30). The slides was irradiated with 30 W, 254 nm UV lamp at 15 cm distance in Sorensen buffer for 30 min, then incubated with 19 SSC (standard saline citrate) at 65 °C for 15 min and stained with 5% Giemsa prepared with Sorensen buffer. Thereafter, the slides were air-dried in dark for 1 week. In order to score SCE, 20 satisfactory metaphases were analyzed. For each treatment condition, well-spread second division metaphases containing 42–46 chromosomes in each cell were scored, and the values obtained were calculated as SCEs per cell.
Bacterial genotoxicity assays
Bacterial strains
Salmonella typhimurium TA1535 (ATCC
® Number: 29629),
S. typhimurium TA1537 (ATCC
® Number: 29630) strains were provided by The American Type Culture Collection – Bacteria Department of Georgetown University, Washington, USA, and
E. coli WP2uvrA (ATCC® Number: 49979) strain was provided by LGC standards Middlesex, UK. All strains were stored at -80 ºC. Working cultures were prepared by inoculating nutrient broth with the frozen cultures, followed by an overnight incubation at 37 ºC with gentle agitation (
31).
Viability assays and determination of test concentrations
Toxic levels of the test materials towards
S. typhimurium TA1535, 1537 and
E. coli WP2uvrA strains were determined as described in detail elsewhere (
32). These tests confirmed that there was normal growth of the background lawn, spontaneous colony numbers within the regular range, and no significant reduction in cell survival. Thus, for the concentrations and conditions reported here, no toxicity or other adverse effects were observed.
Ames-Salmonella and WP2 test systems
The bacterial mutagenicity and anti-mutagenicity assays were performed as described before (
33). The known mutagens NaN
3 (in distilled water -1 µg/plate) for
S. typhimurium TA1535 and 9-AA (in methanol -10 µg/plate) for
S. typhimurium TA1537 were used as positive controls and 10% DMSO was used as negative control in these studies. In the mutagenicity test performed with TA1535 and TA1537 strains of
S. typhimurium, 100 µL of the overnight bacterial culture, 50 µL test compounds at different concentrations (20, 40, 60, 80 and 100 µg/ /plate in 10% DMSO) and 500 µL phosphate buffer were added to 2 mL of the top agar containing 0.5 mM histidine/biotin. The mixture was poured onto minimal glucose plates. Histidine-independent revertant colonies and viable cells were scored on plates after incubation at 37 °C for 48 or 72 h. In the anti-mutagenicity test performed with the same strains, 100 µL of the overnight bacterial culture, 50 µL mutagen, 50 µL test compounds at different concentrations (20, 40, 60, 80 and 100 µg/ /plate in 10% DMSO) and 500 µL phosphate buffer were added to 2 mL of the top agar containing 0.5 mM histidine/biotin. The mixture was poured onto minimal glucose plates. Histidine independent revertant colonies and viable cells were scored on plates after incubation at 37 °C for 48 or 72 h. The procedures of mutagenicity and anti-mutagenicity assays, which are mentioned for the Salmonella assay, are all applicable to the
E. coli-WP2 reverse mutation assay. The only procedural difference is the addition of limited tryptophan (0.05 mM) instead of histidine to the top agar (
34). The plate incorporation method was used to assess the results of mutagenicity and anti-mutagenicity assays (
33,
34). For the mutagenicity assays, the mutagenic index was calculated for each concentration, which is the average number of revertants per plate divided by the average number of revertants per plate with the negative (solvent) control. A sample was considered as mutagenic when a dose-response relationship and a two fold increase in the number of revertants with at least one concentration were observed (
35). For the anti-mutagenicity assays, the inhibition rate (%) of mutagenicity was calculated by using the following equation (M: number of revertants/plate induced by mutagen alone, S0: number of spontaneous revertants, S1: number of revertants/plate induced by the extract plus the mutagen). %Inhibition = 1-[(M-S1) / (M-S0)] ×100 25–40% inhibition was defined as moderate anti-mutagenicity; 40% or more inhibition as strong anti-mutagenicity; and 25% inhibition as no anti-mutagenicity (
36).
Biochemical analysis
Superoxide dismutase (SOD) assay
Cu-Zn-SOD activity of the whole blood cell culture supernatant was evaluated by the method of Sun and others (
37). In the assay, 2.45 mL of assay reagent [0.3 mM xanthine, 0.6 mM Na
2EDTA, 0.15 mM nitroblue tetrazolium (NBT), 0.4 M Na
2CO
3, and 1 g/L bovine serum albumin] was combined with equal amount of protein from each experimental group (
38) and 50 µL xanthine oxidase was added to initiate the reaction. The reduction of NBT by superoxide anion radicals was determined by measuring the absorbance at 560 nm. Cu, Zn-SOD activity was expressed in units of SOD per mg protein, where 1 U was determined as the amount of enzyme causing half-maximal inhibition of NBT reduction.
Glutathion (GSH) assay
GSH levels in the whole blood cell culture supernatant were assessed according to the method described by Anderson
et al. (
39). In a 3 mL cuvette, 750 µL of 10 mM 5-5’-dithio-bis-2-nitrobenzoic acid (DTNB) solution (100 mM KH
2PO
4 plus 5 mM Na
2EDTA, pH 7.5 and GSH-RD, 625 U/L) was combined with equal amount of protein from each experimental group (
40). To each sample 150 µL of 1.47 mM ß-NADPH was added after a 3 min incubation period at room temperature. The mixture was rapidly mixed by inversion and the rate of 5-thio-2-nitrobenzoic acid formation was measured photometrically for 2 min at 412 nm. The reference cuvette contained equal concentrations of DTNB and NADPH but no sample. Values were presented as µmol per gram protein.
Glutathione peroxidase (GPx) assay
GPx activity of the whole blood cell culture supernatant was measured by the method described by Paglia and Valentine (
40). In the assay, 100 µL of 8 mM NADPH, 100 µL of 150 mM reduced GSH, 20 µL of glutathione reductase (30 units/mL), 20 µL of 0.12 M sodium azide solution and 2.65 mL of 50 mM potassium phosphate buffer (pH 7.0, 5 mM EDTA) was combined with equal amount of protein from each experimental group (
38). The samples were incubated for 30 min at 37 °C.
The reaction was initiated by the addition of 100 µL of 2 mM H2O2 solution and the conversion of NADPH to NADP was measured photometrically for 5 min at 340 nm. The enzyme activity was expressed as units per g protein using an extinction coefficient of 6.22 × 10-6 for NADPH at 340 nm.
Malanoaldehyde (MDA) assay
MDA levels in the whole blood cell culture supernatant were determined spectrophotometrically according to the method described by Ohkawa
et al. (
41). A mixture of 8.1% sodium dodecyl sulphate, 20% acetic acid and 0.9% thiobarbituric acid was combined with equal amount of protein from each experimental group (
38). Distilled water was added to the mixture to make the total volume 4mL. This mixture was incubated at 95 °C for 1 h. After incubation, the samples were left to cool under cold water, 1 mL distilled water and 5 mL n-butanol/pyridine (15:1, v/v) were added to the solution and mixed thoroughly. The samples were centrifuged at 4000 rpm for 10 min. The supernatants were separated and measured at 532 nm.
The level of MDA was calculated from a standard graph made by using different concentrations (1-10 nmol) of 1, 1, 3, 3-tetramethoxypropane and was expressed as µmol of formed MDA mL of serum.
Statistical analysis
Statistical significances of the SCE frequencies were determined using a one-way ANOVA analysis followed by a high range statistical domain using Turkey’s test. A level of probability of p <0.05 was taken as indicating statistical significance. Results were expressed as mean ± S.E. All experiments were performed in three replicates and data was compared for reproducibility.
